Cathedral Ceiling Adapter

Combine this ceiling fixture with a ceiling mount when attaching the assembly to an angled ceiling.

TECHNICAL DATA:
COMPONENTS:


MODEL#: ACC 556
WEIGHT: 1.8 (3)
SHIPPING WEIGHT: 4 (5)
MAXIMUM LOAD: 250 LB. (113 KG.)

NOTES:
MATERIAL: COLD ROLLED STEEL
FINISH: WHITE FUSED EPOXY
ALL DIMENSIONS: IN. (MM), ALL WEIGHTS: LB. (KG.)
MAXIMUM LOAD IS THE COMBINED WEIGHT OF ALL ATTACHED HARDWARE AND COMPONENTS
ARCHITECT SPECIFICATIONS:
The TV mount ceiling fixture shall be an ACC 556 Cathedral Ceiling Adapter, or equivalent, and shall be mounted where indicated on the plans. It shall be used in combination with a mounting bracket or other equipment specified as compatible by the manufacturer. It shall include wood screws for attachment to a wood joist ceiling. It shall be constructed of heavy gage cold rolled steel and finished in white fused epoxy. It shall be UL Listed. Assembly and installation shall be done according to the instructions provided by the manufacturer.
