Vivitek DU8090Z-BK

1-DLP Projector, Laser Light Source, 1920x1200 WUXGA, 8000 Lumens, No Lens, Black, 5 year warranty
Item #0601-8335 Model #DU8090ZBK

Overview

Impressive Brightness and Abundant Features for an Exceptional Large Screen Experience

The DU8090Z laser light source projector takes projection to the next level, with impressively vivid colors and a high brightness of 8,000 ANSI lumens. Built lamp-free, it provides a low cost of ownership, with minimal maintenance, and gives a stable, high-quality projection for up to 20,000 hours. Complete lens set together with a full feature set the DU8090Z offers the best performance and value in the next generation of advanced technology projection - laser. The DU8090Z offers the most immersive big-screen experience available in digital projection.

  • Laser phosphor projection engine incorporates a laser design that’s long lasting(20,000 hrs)and environmentally friendly
  • 8,000 ANSI lumens*, with a dynamic 10,000:1 contrast ratio, provide amazing image quality that's stable over time
  • Built-in ACS (auto color sensor) for color and brightness consistency
  • Built-in MPS (multi projector system) hardware for edge blending, flexible geometry and warping functionality
  • Powered zoom, focus and lens shift (horizontal/vertical) for easy adjustment and projector position flexibility together with memory system
  • Picture-in-Picture (PIP) to simultaneously project images/videos from two different sources
  • Full suite of display connectivity inputs and outputs including: HDMI v1.4a, DVI-D, Component (5 BNC), VGA-In, 3G-SDI-In/Out, VGA-Out, HDBaseT™ (content over CAT5e/6 cable)
  • Full 3D compatibility with DLP® Link™ and HDMI 1.4 interface
  • Flexible mounting positioning - 360 degrees in any axis for ease of installation
  • Network connectivity for remote projector management - control and status. Ready for integration and system administration via RJ45
  • Eight interchangeable lens options for flexible installation and optimized brightness
  • Sealed optical engine and filter-less design improves performance with minimal service maintenance
  • Choose the color to best fit your environment, with black and white cabinet colors available
  • Instant On/Off
  • Sealed optical engine and filter-less design improves performance with minimal service maintenance.

Specifications

Brightness 8000 ANSI Lumens
Native Resolution WUXGA (1920 x 1200)
Contrast Ratio 10,000:1 (Full On/Off)
Display Type Single 0.67” DLP® Technology by Texas Instruments
Image Size (Diagonal) 40" to 500" (1.0 to 12.7 m)
Aspect Ratio 16:10 Native
Lens Shift Motorized, up to 0-50% Vertical, ±10% Horizontal, except with ultra-short and wide fixed lenses
Keystone Correction ±40° Vertical, Horizontal ±60°
Horizontal Scan Rate 15 to 108 KHz
Vertical Scan Rate 50 to 85 Hz
Projection Method Table Top or Ceiling Mount (Front or Rear)
Computer Compatibility VGA, SVGA, XGA, WXGA,SXGA, SXGA+, UXGA, 1080P, WUXGA at 60 Hz, Max
Video Compatibility SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i/p) NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I, M, N), SECAM (B, D, G, K, K1, L), WUXGA at 60 Hz Max
3D Functionality DLP® Link™, HDMI v1.4 (Blu-ray, Side by Side, Frame Packing, Top and Bottom)
I/O Connection Ports HDMI v1.4a (x2) DVI-D, Component (5 BNC), VGA-In, 3G-SDI-In/Out, RS-232, VGA-Out, 3D-Sync In/Out, 12v Trigger, Wired Remote, HDBaseT™/LAN (Shared)
Security Kensington ® Security Slot, Security Bar, Pin Lock Keypad, Anti-Theft Lens Screw
Weight 61.7 lbs (28kg)
Dimensions (W x H x D) 19.7" x 22.8" x 8.1" (500 x 580 x 205 mm)
Noise Level 40dB (Standard)
Power AC 100-240 V, 50/60 Hz
Standard Accessories Replacement Lamp, AC Power Cord, Remote, Lens Cap, Anti-Theft Lens Screw, Documentation Kit
Optional Accessories Interchangeable Lens Options (x8), NovoPRO

Accessories

Optional Lenses

Model D88-UST011,2,3 D88-UWZ011 D88-WF185011,3 D88-WZ01

D88-ST001
Std Lens

 D88-SMLZ01 D88-LOZ101 D88-LOZ201
P/N 3797866500-SVK 3797804200-SVK 3797745100-SVK 3797745200-SVK 3797744200-SVK 3797745000-SVK 3797745400-SVK 3797744900-SVK
Price $5,495.00
Add to Cart 		$3,482.00
Add to Cart 		$2,613.00
Add to Cart 		$2,613.00
Add to Cart 		$1,315.00
Add to Cart 		$2,613.00
Add to Cart 		$2,613.00
Add to Cart 		$2,613.00
Add to Cart
Vivitek D88-UST01B lens Vivitek D88-UWz01 lens Vivitek D88-WF18501 lens Vivitek D88-WZ01 lens Vivitek D88-ST001 lens Vivitek D88-SMLZ01 lens Vivitek D88-LOZ101 lens Vivitek D88-LOZ201 lens
D:W
WUXGA/1080p		 0.38:1 0.75 – 0.93:1 0.76:1 1.25 – 1.79:1 1.73 – 2.27:1 2.22 – 3.67:1 3.58 – 5.38:1 5.34 – 8.26:1
f/stop 2.0 1.96 – 2.3 1.85 1.85 – 2.5 1.7 – 1.9 1.86 – 2.48 1.85 – 2.41 1.85 – 2.48

Notes

1 Not compatible with D8800, D8900, D8010W.

2 Lens support required. Bracket provided works with DU6871, DU8090Z, DU8190Z, DU893Z, and DK8500Z

3 Not compatible with Lens shift.

Downloads

Warranty

5-Year Warranty on Parts and Labor or 20,000 hours; whichever comes first / 3-Year Advanced Exchange
