Amino H200W

High-performance 4K UHD Media Player with Built-in Wi-Fi

The Amino H200W expands upon the success of the H200 series by integrating Wi-Fi 6 and Bluetooth (BLE 5.2) technologies, providing unmatched deployment flexibility and enhanced performance for digital signage and enterprise video applications.

This addition offers significant advantages in markets like retail, where the costs associated with cabling and deployment of wired solutions can be prohibitive. Wi-Fi 6's robustness in congested or noisy spectrum environments makes it ideal for signage applications, while the inclusion of Bluetooth opens up possibilities for innovative use cases such as audience presence detection and improved content caching.

Engineered for quick and seamless setup, the H200W offers simple setup wizards, cloud management options, and support for pre-certified CMS partner applications, making it an intuitive solution for most digital signage environments.

Key features include a built-in web browser, JavaScript SDK, and management API interface, giving systems integrators all the tools they need for easy deployment. For added convenience, the H200W supports both local management APIs and cloud-hosted management through Amino's Orchestrate platform, ensuring you can monitor and manage devices over any IP network with ease.

With a rugged case and a high-performance processor with AV1, HEVC & AVC video decode, the H200W ensures fast, high-quality user experience.

Key Features

• Wi-Fi 6 and 2 external detachable antenna 2x2 802.11ax

• Bluetooth v5.2

• AV1/HEVC 4Kp60 provides high quality images at reduced bandwidth

• Out-of-sight operation using TVI serial interface or IR extender port as standard

• Tamper-proof, ruggedized chassis

• Integrated mounting brackets (VESA) to fit behind a screen for digital signage apps or underneath a desk for hospitality apps

‍

• Device Management: Offers options for local or remote device management, such as REST API for media player management on closed or private networks, and the Orchestrate SaaS solution allowing remote management and support for connected devices.

• Channel Zapper: Built-in application for easy access and decoding of IP streams, simplifying the user experience.

• Multi-decode function: Versatile multi-decode capabilities, supporting side-by-side broadcasts, picture-in-picture, and mosaic displays for live video and signage usage. With support for single 4Kp60, Dual 4Kp30, Quad 1080p60, and multiples of SD decode, you can create dynamic content arrangements tailored to your needs.

• Low-Latency streaming: Real-time video decoding with low-latency streaming capabilities for seamless viewing of fast-paced, time-sensitive content. The low-latency protocols supported include LL-HLS, LL-DASH, Web-RTC and Secure Reliable Transport (SRT).

• Robust Secure Design: Tamper-proof and ruggedized chassis for durability and resistance to unauthorized access, ensuring reliable performance in demanding environments.

• Security and Firmware Updates: Amino provides regular quarterly security releases to ensure your device's firmware is up-to-date, enhancing security and reliability while safeguarding the integrity of your content.

• Built-in Browser Component: Enables execution of web/HTML5-based applications, offering interactive and engaging content experiences.

• Web Development SDK: Includes media-centric customized browser that supports an extensive set of Javascript APIs and a sample media player application that can be extended to provide a unique interactive viewing experience. The SDK enables use cases that include device management and control as well as video playback of Amino-supported streaming formats.

• Command Scheduler API: A powerful set of APIs that allow for scheduling of events and activities at the operating system level, which provides functionality outside of the set of installed applications and even allows the ability to switch focus between them programmatically.

• Optimized Content Delivery: The H200W delivers high-quality images, videos and graphics at reduced bandwidth with its AV1/HEVC 4Kp60 capability, ensuring an immersive visual experience without buffering or pixelation.

• Out-of-sight Operation: Designed for discreet operation with IR extender port, and integrated mounting brackets (VESA) for easy installation and unobtrusive user experience.

• Ease of Installation: Simplifies deployment and installation across various environments with zero-touch provisioning through device management options, and a simple setup wizard.

• Pre-integrated CMS solutions: supports a range of accredited CMS solutions, fully optimized to deliver top performance and comprehensive support, ensuring your content management experience is streamlined and efficient.

Processing

Interfaces

Software

Video & Audio Formats

Networking & Security

Power

Operating Environment

Physical Properties & Mechanics
