Digital Projection E-Vision 6110-WU

DP E-Vision 6110-WU Laser DLP Projector, WUXGA, 5500 ANSI Lumens, 0.5:1, 3-Year Warranty
Item #0600-3000 Model #EVISION6110WU

Overview

DP E-Vision 6110-WU

Incredibly budget-friendly high-brightness laser projector

Compact and powerful, the E-Vision 6110-WU delivers an impressive 6,100 lumens and weighs in at only 26.5 lb (12 kg), offering a very quiet operation noise of only 39 dBA. This single chip DLP Laser projector produces 20,000 hours of stable and near maintenance-free illumination.

The E-Vision 6110-WU projector includes an ultra-short throw 0.5:1 fixed lens with a 0.6 offset, allowing it to be mounted well above the screen and out of the line of sight of viewers. This lens option makes it an impressively compact, entry-level imaging solution ideal for museums, lecture theaters, corporate boardrooms, digital signage and similar applications needing bright imagery at remarkably accessible price points.

With a multitude of connectivity options and a packed feature list of video and graphics processing, this projector also offers 10-bit color display and a 4 Segment (RGBY) Colour wheel, ensuring excellent color reproduction.



Key Features:
  • 6,100 Lumens (5,500 ANSI Lumens)
  • WUXGA Resolution
  • 500,000:1 Advanced Black Contrast

Features

  • High Brightness: The E-Vision 6110-WU produces up to 6,100 lumens (5,500 ANSI lumens)
  • Multi-Axis Orientation: For maximum flexibility, the E-Vision 6110-WU can be operated in both Portrait and Landscape mode, pointing up and down and every angle in between
  • Geometry Correction: The E-Vision 6110-WU has built in vertical keystone correction, which allows the correction of the image when the projector is mounted at an angle

  • Low weight and compact: weighs only 26.5 lb (12 kg), great as an entry-level laser projector
  • Ultra-short throw lens: The 0.5:1 fixed lens with a 0.6 offset allows it to be mounted well above the screen and out of the line of sight of viewers.
  • 10-bit color display and 4 Segment (RGBY) Colour wheel: guarantees excellent color reproduction.
  • 3D Laser Projector: supports the following 3D formats:
    • Frame Packing
    • Frame Sequential
    • Side By Side (half)
    • Top and Bottom
  • 3-Year Warranty: Due to the proven reliability and long-term performance of their precision displays, Digital Projection provides a full 3 years of parts and labor coverage for projectors employed in standard use applications.

Specifications

Color System

Laser Phosphor

Display Type

1 x 0.67" DarkChip™ DMD™

DMD Specification

1920 x 1200 pixels native resolution.

Fast transit pixels for smooth greyscale and improved contrast.

Aspect Ratio

16x10

KEY FEATURES

Video & Graphics Processing

  • HDMI 1.4a mandatory compliance for Side by Side, Frame Packing, Frame Sequential and TopBottom 3D Formats.
  • Synchronisation of active glasses or polarizing switcher.
  • DICOM simulation mode

Geometry Correction

  • Vertical & Horizontal Keystone correction
  • Four Corner adjustment
  • Selectable aspect ratios: Fill, 4:3, 16:9, Letter Box, Native, 2.35:1
  • Digital Zoom +10 / -10

HDBaseT Interface

  • Built in support for transmission of uncompressed High Defínition Video over standard CAT5e/6 LAN cable.
  • Allows the projector to be placed up to 100 m from the source with low cost cabling.
  • HDBaseT® Includes Audio, Ethernet 100BaseT and RS232/IR control.

Color Processing

  • Phosphor wheel: 3 Segment GBY 2 x 7200 rpm
  • Color wheel: 4 Segment RGBW 2 x 7200 rpm
  • 10-bit color processing (30-bits per pixel)
  • Powerful seven point color correction for accurate color matching.

Source Compatibility

  • Graphics standards up to 1920 x 1200 resolution at 60 Hz
Input Terminals
  • VGA in x1
  • Mini-jack Stereo x1
  • Composite video x1
  • HDMI (MHL) x1, HDMI x2
  • Audio RCA (R/L) x1
  • HDBaseT x1
  • Mini-jack Microphone x1
Output Terminals
  • VGA x1
  • Audio out x1
  • USB Type A for power support on WHDI x1
  • 3D-Sync x1
Control Terminals
  • RS-232C x1
  • RJ45 x1 (10/100 Mbps)
  • USB mini B for service x1
3D Formats Supported Frame Packing
Frame Sequential
Side By Side (half)
Top and Bottom
HDTV Formats Supported SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N), SECAM (B,D,G,K,K1,L)
Computer Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA@60Hz, Mac
Remote Control IR remote control
Automation Control LAN
RS-232
Alert Mail for Projector
LAN Control-Crestron® Roomview™-Connected
LAN Control-Crestron® eControl
LAN control - Extron®
LAN Control-PJ Link compatible
LAN Control-AMX® SSDP
LAN to RS232 (RS232 by Telnet)
Concurrence Control for RS232/LAN
PJ Link (Class 1)
Color Temperature Warm / Normal / Cold
Operation 24x7 operation
illumination Type Laser Light Source
Typical illumination Life 20,000 hours
LENS

Throw ratio: 0.5:1 (fixed)

Optimized Focus Range*: 0.76–1.35 m (optical range), 0.60–3.5 m (mechanical range)

Lens Shift (Frame): Vert: Fixed Offset 0.6 (U) frame

* Lens focal ranges above are the optimized distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: ±3%. HighLite Series: ±5%. M-Vision Series: ±2%. Titan Series: ±2%, INSIGHT Series: ±2%

Lens Mount Manual focus
Mechanical Mounting Front/Rear
Front/Rear Ceiling
Two adjustable front feet, 10° (43mm)
Ceiling Mount compatible chassis with 7 off M4 mounting holes
Kensington® Security Slot
Orientation Table Top or Inverted: Yes
Pointing Up:        Yes
Pointing Down:   Yes
Roll (Portrait):      Yes
Power Requirements 100-240 V AC 50/60 Hz single phase
Power Consumption 515 W @ 230 V AC (100% Normal mode) Maximum 530 W @ 100 V AC (100% Normal mode) Maximum
Thermal Dissipation 1757 BTU/Hour @ 230 V AC (100% Normal mode)
1808 BTU/Hour @ 100 V AC (100% Normal mode)
Fan Noise Normal Mode Typ: 39 dBA
Temperature Operating: 32°F to 104°F (0° to 40°C)
Storage:    -4°F to 140°F (-20° to 60°C)
Operating Humidity 10 to 85% non-condensing
Weight 26.45 lb (12 kg)
Dimensions (LxWxH) 17.2" x 14.17" x 7.02" (437.1 x 360 x 178.3 mm)
Safety & EMC Regulations UL / cUL (USA/Canada), CB, CCC (China), FCC Class B (USA), FDA, CE (European Economic Area), RCM (Australia), Others TBD
