Digital Projection 124-319

DP 124-319 Short-Throw Zoom Lens, 0.55-0.75:1
Item #0600-3111 Model #124319

Specifications

Digital Projection 124-319

Short Throw Zoom Lens

The Digital Projection 124-319 lens is a short throw 1.36x zoom lens. This lens has an F-stop of 2.03–2.34, and a focal length of 10.03–13.54 mm. It also features power zoom and power focus capabilities for remote adjustment.

The 124-319 lens is designed for Digital Projection E-Vision projectors such as the 10000i 4K+, 10000i WU and 8000i WU. Please check the Compatibility tab to make sure this lens will work with your projector.



Specifications

Throw ratio 0.55~0.75:1 (0.8" chip)1
0.65~0.89:1 (0.67" chip)2
F-stop 2.03–2.34
Focal length 10.03–13.54 mm
Optimized Focus Range 3

2.26–21.59 ft / 0.69–6.58 m (0.8" chip)1
2.69–25.69 ft / 0.82–7.83 m (0.67" chip)2
Vertical lens shift ±50% (0.8" chip)1
±60% (0.67" chip)2
Horizontal lens shift ±20% (0.8" chip)1
±20% (0.67" chip)2

1 For WUXGA, 0.8" HEP DMD projectors such as the 10000i 4K+

2 For WUXGA, 0.67" VSP DMD projectors such as the 10000i WU and 8000i WU

3 Lens focal ranges above are the optimized distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances for E-Vision Series: ±3%.
