Epson L20002UNL
Laser LCD Projector WUXGA, 20K Lumens, No Lens, White
Item #0600-6161 Model #V11H833920
Overview
Epson Pro L20002UNL
Premium WUXGA 3LCD laser projector with 20,000 lumens
The Epson Pro L20002UNL combines a laser light source and 3LCD technology for powerful, lifelike images, delivering outstanding brightness in a remarkably compact 3-chip projector.
A premium large-venue projector, it features Full HD WUXGA resolution and 20,000 lumens of color/white brightness for ultra bright, vivid color. Its laser light engine and electrostatic air filter provide virtually maintenance-free operation for up to 20,000 hours.
With two interface slots designed to accommodate a wide range of inputs, the Pro L20002UNL provides the ultimate in connectivity. It also supports optional lenses (sold separately), including a zero-offset ultra short-throw lens.
The Epson Pro L20002UNL sets a new standard for large-venue presentations, combining superb image quality with flexibility and ease of use. Whether it's for educational purposes, entertainment, or professional presentations, this Epson 3LCD laser projector enhances every visual experience with stunning clarity and color.
Projector also available in black as the Epson Pro L20000UNL.
Features
Key Features
- Ultra bright, vivid color — 20,000 lumens color/white brightness1; advanced 3-chip, 3CLD technology
- Exceptional widescreen display — Full HD WUXGA (1920 x 1200) resolution; accepts 4K content and provides 2.3 million pixels on screen
- Solid-state laser light source — with electrostatic air filter for up to 20,000 hours of virtually maintenance-free operation2
- Wide range of optional lenses (sold separately) — including a zero-offset ultra short-throw lens
- Powerful — outstanding brightness from a remarkably compact large-venue projector
- Advanced connectivity — two interface slots accommodate a wide range of inputs
Other Features
- Designed for demanding environments — features a sealed light source and optical engine for outstanding durability for live events and fixed installations
- Dynamic projection capabilities — with advanced tools like tiling assist, Edge Blending, and auto-color adjustment for fast installation; free software for multi-projector setup
- Bold, vibrant images — supports High Dynamic Range (HDR) via HDR10 (PQ) and Hybrid Log Gamma (HLG); BT.709 color space
- Mechanical shutter — protects against damage from external laser lights
- Frame interpolation — ideal for fast-moving images
- Wide lens shift — optimized lens and optical engine design
Eco Features
- RoHS compliant
- Recyclable product3
- Epson America, Inc. is a SmartWay™ Transport Partner4
Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118. Some lenses will not support the maximum brightness level of this projector.
2 No required maintenance for the light source and filter up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period. The projector has a limited warranty of 3 years or 20,000 hours, whichever comes first.
3 For convenient and reasonable recycling options, visit www.epson.com/recycle
4 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
2 No required maintenance for the light source and filter up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period. The projector has a limited warranty of 3 years or 20,000 hours, whichever comes first.
3 For convenient and reasonable recycling options, visit www.epson.com/recycle
4 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
Specifications
Specifications Projector:
| Projection System: | High-aperture Epson® 3LCD, 3-chip technology |
| Projection Method: | Front / rear / ceiling mount |
| Driving Method: | Poly-silicon TFT Active Matrix |
| Pixel Number: | 2,304,000 pixels (1920 x 1200) x 3 chips |
| Color Brightness - Color Light Output: | 20,000 lumens1 |
| White Brightness - White Light Output: | 20,000 lumens1 |
| Aspect Ratio: | 16:10, 16:9, 4:3 |
| Resolution: | WUXGA (1920 x 1200) |
| Brightness Uniformity: | 90% |
| Pixel Arrangement: | Cross stripe |
| Contrast Ratio: | 2,500,000:1 |
| Color Reproduction: | Up to 1.07 billion colors |
| Light Source Life: | 20,000 hours (Normal); 30,000 hours (Extended)2 |
| Laser Type: | Laser Diode |
General:
| Operating Temperature: | 32° to 113° F (0° to 45° C) |
| Power Supply Voltage: | 100–240 V ±10%, 50/60 Hz AC. Requires 200–240 V for full spec. operation |
| Power Consumption: | 1860 W (Normal Mode) 1123 W (Extended Mode) 2.0 W Standby (Communication on) 0.5 W Standby (Communication off) |
| Dimensions (WxHxD): | 24.4" x 14.1" x 31.1" (620 x 358.5 x 790 mm) (including feet) |
| Weight: | 109.3 lb (without standard lens, not included) |
| Security: | Security cable hole, Kensington lock provision |
Projection Lens (not included):
| Type: | Powered shift/focus/zoom (ELPLM15 Lens) |
| F-number: | 1.8 – 2.35 (ELPLM15 Lens) |
| Focal Length: | 36.0 mm – 57.4 mm (ELPLM15 Lens) |
| Zoom Ratio: | Optical zoom 1 – 1.6x (ELPLM15 Lens) |
| Throw Ratio Range: | 1.57 – 2.56 (ELPLM15 Lens) |
| Lens Shift: | Vertical: ±60 percent; Horizontal: ±18 percent (ELPLM15 Lens) |
Projector Details:
| Input Signal: | Input Video Signal (HDMI, DVI-D and HDBaseT ports) 480i/480p/576i/576p/720p/1080i/1080p/3840 x 2160/4096 x 2160 |
| Interfaces: |
|
| Interface (Slot 1) |
|
| Interface (Slot 2) |
|
| Other |
|
| Fan Noise: | 45 dB (Normal Mode); max. 38 dB (Quiet Mode) |
Remote Control:
| Features: | Power, Search Selection, Lens Shift, Zoom, Focus, Test Pattern Selection, Shutter, Freeze, User ID, Auto, Aspect, Color Mode, Menu, Slot 1, Slot 2 and more |
| Operating Distance: | 49 ft |
| Operating Angle: | Right/left: front: ±50 degrees; rear: ±40 degrees Upper/lower: front: ±50 degrees; rear: +30 degrees |
Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118. Some lenses will not support the maximum brightness level of this projector.
2 No required maintenance for the light source and filter up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04–0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period. The projector has a limited warranty of 3 years or 20,000 hours, whichever comes first.
2 No required maintenance for the light source and filter up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04–0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period. The projector has a limited warranty of 3 years or 20,000 hours, whichever comes first.
Accessories
Optional Lenses
| Model: | ELPLX02S1 ELPLX022 |
ELPLU03S | ELPLU04 | Z-ELPLW04.8 | ELPLW083 | ELPLW06 |
ELPLM15 |
ELPLM10 | ELPLM11 | ELPLL08 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
| D:W WUXGA 1.03" chip |
0.35:1 | 0.48 –0.57:1 | 0.64–0.77:1 | 0.73–1.19:1 | 0.86–1.21:1 | 1.19–1.62:1 | 1.57–2.56:1 | 2.42–3.71:1 | 3.54–5.41:1 | 5.27–7.41:1 |
| F/stop | 1.9 | 2.0–2.26 | 2.0–2.1 | 1.7–2.0 | 2.0–2.2 | 1.8–2.3 | 1.8–2.35 | 1.8–2.4 | 1.8–2.4 | 1.8–2.5 |
| Max Lumens | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 | 20,000 |
1 ELPLX02S has a mounting point for the ELPEC01 external camera.
2 ELPLX02 is discontinued.
3 Z-ELPLW04.8 is more cost effective.
Other accessories
 |
Ceiling mounts | |
 |
Replacement air filter (ELPAF58) | |
 |
HDBaseT transmitter (ELPHD01) |
|
 |
HDMI/DVI-D Interface Board (ELPIF01) |
Add to Cart |
 |
DisplayPort Interface Board (ELPIF03) |
Add to Cart |
Downloads
Epson Projector Professional Tool Operation Guide (see below)
Epson Projector Professional Tool Software
- Intuitive operation and control — manage multiple networked projectors
- Save time — spend less time making adjustments via a remote control
- Powerful projection tools — easily access tools such as geometric correction and Edge Blending
- Simple setup — projectors in the same network are automatically found and displayed
- Compatible — works with Windows 7/8.1/10 devices and displays with WXGA or higher resolution; supports Epson Pro L1000 Series, Pro L12000Q, Pro L20000U and Pro L25000U projectors
- Convenient — supports wired and wireless networks
- Auto calibration and screen matching — to quickly adjust the brightness and color of networked projectors via their built-in cameras
