Epson PowerLite L510U

Laser Projector, 1920x1200 WUXGA, 5000 Lumens, 360 Degree, HDBaseT, D:W 1.38-2.24:1, White, 3 Year Warranty
Part #: 0600-6249    Mfr #: V11H903020

Epson PowerLite L510U

Overview

PowerLite L510U

Robust, compact WUXGA laser projector with 5,000 lumens plus lens shift.

The compact, affordable PowerLite L510U laser projector delivers powerful performance for education and business applications. Get bright, vivid images with 5,000 lumens color/white brightness, and a dynamic contrast ratio of up to 2,500,000:1.

This robust projector also offers WUXGA resolution and Full HD support. Featuring breakthrough laser technology, it delivers a laser light source of up to 20,000 hours. And, it offers virtually maintenance-free operation for the life of the optical engine.

It also includes manual lens shift, enterprise-level wireless security support (module sold separately), and advanced installation features.

Features

Key Features

  • Bright, vivid color: 5,000 lumens color/white brightness1.

  • Full HD, widescreen images up to 500"

  • WUXGA resolution (1920 x 1200); Full HD 1080p support

  • Breakthrough laser technology features a laser light source of up to 20,000 hours2; plus Instant ON/OFF
  • Virtually maintenance-free operation for the life of the optical engine3
  • Extraordinary sharpness and detail: up to 2,500,000:1 dynamic contrast ratio
  • Flexible installation: up to ±50 percent vertical and ±20 percent horizontal manual lens shift

Other Features

  • Optional wireless networking with enterprise-level security, plus wireless content sharing with Epson iProjection™4; wireless module sold separately
  • Robust connectivity supports HDBaseT™, 2x HDMI®, VGA, RJ-45, stereo mini and control management tools
  • Advanced installation features: 360-degree flexibility and geometric correction tools such as horizontal and vertical keystone, arc correction, Quick Corner® and more
  • Constant Brightness Mode5: fine-tune the brightness setting to help maximize run time

Eco Features

  • RoHS compliant
  • Recyclable product6
  • Epson America, Inc. is a SmartWay™ Transport Partner7

Notes:
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 20,000 hours is the estimated laser light source life when used in Normal Mode. Actual hours may vary depending on mode and usage environment. The projector has a standard limited warranty of 3 years.

3 Life of the optical engine may vary depending on mode and usage environment. The projector has a standard limited warranty of 3 years.

4 For wireless functionality, including via the Epson iProjection App, the projector must be configured on a network, either through the Ethernet port on the projector (check model specifications for availability) or via a wireless connection. Check your owner’s manual to determine if a wireless LAN module must be purchased separately to enable a wireless connection. Not all Epson projectors are able to be networked. The Epson iProjection App does not support all files and formats. See www.epson.com for details.

5 Color light output and white light output (lumens) in Constant Brightness Mode can be lower than the maximum output achievable when the Constant Brightness Mode is off. Actual run time may vary depending on environmental conditions, usage and settings.

6 For convenient and reasonable recycling options, visit www.epson.com/recycle

7 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.

Specifications

Specifications Projector:

Projection System:

RGB Liquid Crystal Shutter Projection System

Projection Method:

Front, Front/Ceiling, Rear, Rear/Ceiling

LCD Screen:

0.67" (D10 with C2Fine™)

Driving Method:

Poly-silicon TFT Active Matrix

Pixel Number:

2,304,000 pixels (1920 x 1200) x 3

Color Brightness - Color Light Output:

5,000 lumens1

White Brightness - White Light Output:

5,000 lumens1

Aspect Ratio:

16:10

Native Resolution:

1920 x 1200 (WUXGA)

Throw Ratio Range:

1.35–2.2

Size - projected distance:

80" screen: 2.33–3.78 m

Keystone Correction:

Vertical: ±30 degrees; Horizontal: ±30 degrees

Contrast Ratio:

Up to 2,500,000:1

Color Processing:

10 bit

Color Reproduction:

Up to 1.07 billion colors

Light Source Life:

Normal: 20,000 hours; Quiet: 20,000 hours; Extended: 30,000 hours

Laser Type:

Laser Diode



Effective Scanning Frequency Range:

Pixel Clock:

Analog: 13.5–162 MHz (up to UXGA 60 Hz)
Digital: 13.5–162 MHz (up to UXGA 60 Hz)

Horizontal:

Analog: 15–92 kHz
Digital: 15–75 kHz

Vertical:

Analog: 50–85 Hz
Digital: 24/30/50/60 Hz



Projection Lens:

Type:

Optical Zoom (Manual)/Focus (Manual)

F-number:

1.5–1.7

Screen Size:

Zoom: Wide: 50"–500" [1.44–14.76 m]; Zoom: Tele: 50"–500" [2.35–23.84 m]

Focal Length:

20.0–31.8 mm

Zoom Ratio:

1–1.6

Lens Cover:

Lens cap (without string)



Projector Details:

Interfaces:

  • HDBaseT 1x
  • 2x HDMI
  • Analog: D-sub 15 pin
  • 1x Control I/O: RS-232C D-sub 9 pin
  • USB-I/O: Type A 1x; Type B 1x
  • Wired LAN RJ45
  • Wireless LAN Optional Accessory
  • Audio in (stereo): 2x
  • Audio out (stereo): 1x

Fan Noise:

37 dB (Normal Mode), 25 dB (ECO Mode)



Projector Dimensions:

Including feet:

17.32" x 11.97" x 5.35" (W x D x H)

Excluding feet:

17.32" x 11.97" x 4.73" (W x D x H)

Weight - with standard lens:

Approx. 18.7 lb/8.45 kg



Remote Control:

Operating Distance:

8 m

Operating Angle:

  • Front: Right/Left: ±60 degrees; Upper/Lower: +30 to -20 degrees
  • Rear: Right/Left: ±30 degrees; Upper/Lower: +50 to +10 degrees



Power:

Power Supply Voltage:

100 – 240 V ±10%, 50/60 Hz AC

Power Consumption:

Normal: 353 W; Quiet: 254 W; Networked Standby 2.0 W; Energy Saving: 0.3 W



What's in the Box:

  • PowerLite L510U Projector
  • Power cord
  • Computer cable (VGA)
  • Remote control and batteries
  • Quick setup poster
  • Cable cover

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
