Panasonic PT-VX610U

LCD Projector, 1024x768 XGA, 5500 Lumens, Vertical Lens Shift, D:W 1.17-1.90:1, 3-Year Warranty
Item #0600-7086 Model #PTVX610U

Overview

Panasonic PT-VX610U

3LCD Portable Projector

Designed for education and corporate applications, the PT-VX610U features high brightness in a compact and lightweight body.

Get the best of both worlds: use this projector as a high-brightness portable for large boardrooms, meeting spaces, and classrooms, or as an easily-managed ceiling installation solution. However it's used, everybody can serve punchy, pin-sharp pictures in well-lit spaces.

The PT-VX610U is also designed for enhanced efficiency. Its air filter replacement cycle is up to 7000 hours, and the filter can be washed and reused twice to minimize waste. Lamp life is also extended to 7000 hours in ECO2 Mode, meaning both filter and lamp can be replaced together to reduce downtime.



Key Features
  • LCD, 5,500 lumens, XGA
  • Long lamp and filter replacement cycle up to 7,000 hours
  • 16,000:1 contrast ratio

[ Compare to Similar Projectors ]

Features

Supreme Imaging Power

  • High brightness up to 5500 lumens and a 16,000:1 contrast ratio for vivid colors, inky blacks, pure highlights, and clearly legible text
  • 6 colors adjustment and color correction functions, particularly useful for multi-projection side-by-side configurations
  • Efficient low-maintenance design: both filter and lamp can be used for 7,000 hours and replaced at the same time
  • Ability to see image details in well-lit rooms thanks to Daylight View Basic feature and built-in sensor
  • Quiet operation, with noise levels down to 29 dB; the sound of the cooling fan is hardly noticeable

Stress-free Installation

  • 1.6x zoom lens and lens shift function allow you to project from a wide range of distances, from tabletops or ceiling, and quickly adjust image position without distortion.
  • Quick lamp and filter replacement: the filter can be replaced from the side, and the lamp from the top of the projector, without removing the unit from its ceiling mount.
  • The Auto Screen Image Rotation feature automatically rotates the image depending on installation orientation, using a built-in angle sensor.
  • Horizontal, vertical and corner keystone correction adjust the image shape for clear visibility when projecting off-axis or from an unusual angle.

Additional Features

  • DC OUT Terminal
  • Direct Power Off
  • Built-in 10 W Speaker
  • ECO Management Function
  • Whiteboard and Blackboard Mode
  • Emulation Mode
  • Crestron Connected™, AMX DD, and PJ Link™ Compatible
  • Easy Monitoring and Control Over LAN
  • Auto Input Signal Search
  • Early Warming Software Compatible (Option)
  • Startup Logo Function
  • Presentation Support Function
  • Audio Standby Mode
  • Digital Zoom Function
  • Anti-theft Features
  • Closed Captioning (NTSC)

Specifications

Brightness 5500 lumens
Technology LCD
Power supply AC 100-240 V, 50/60 Hz
Power consumption *1 385 W (North America)
When [STANDBY MODE] is set to [ECO] : approx. 0.3 W (North America)
When [STANDBY MODE] is set to [NORMAL] and [IN STANDBY MODE] of
[AUDIO SETTING] is set to [OFF]: approx. 12 W
BTU value 1,314 BTU (North America)
LCD panel | Panel size 16.3 mm (0.64 in.) diagonal (16:10 aspect ratio)
LCD panel | Display method Transparent LCD panel (x3, R/G/B)
LCD panel | Drive method Active matrix method
LCD panel | Pixels 2,304,000 (1920 x 1200) x3, total of 6,912,000 pixels
LENS Manual zoom (1.6x), manual focus,
F 1.6–1.9, f 15.3124.64 mm
Lens | Throw ratio 1.171.90:1
Lamp 280 W UHM lamp
Projection size 0.767.62 m (30-300 in.) diagonally, 16:10 aspect ratio
Colors Full color (16,777,216 colors)
Light output *2 5,500 lumens (Lamp power: Normal, Dynamic mode, Iris off,
Daylight View:off, Auto Power Save:off)
Center-to-corner uniformity 85%
Contrast ratio*2 16,000:1 (all white/all black, Image mode:Dynamic, Lamp power: Normal, Iris: On)
Resolution 1024 x 768 pixels (Input signals that exceed this resolution will be converted to 1024 x 768 pixels.)
Lamp replacement cycle Normal: 5,000 hours, Eco1: 6,000 hours, Eco2: 7,000 hours
Filter replacement cycle 7,000 hours (Period varies depending on usage environment.
It can be washed and reused up to 2 times.)
Scanning frequency | HDMI/DIGITAL LINK

Moving image signal resolution: 480i (525i)*3, 576i (625i)*3, 480p (525p), 576p (625p), 720 (750)/60p, 720 (750)/50p, 1080 (1125)/60i, 1080 (1125)/50i, 1080 (1125)/25p, 1080 (1125)/24p, 1080 (1125)/24sF, 1080 (1125)/30p, 1080 (1125)/60p, 1080 (1125)/50p

Still image signal resolution: 640 x 400 to 1920 x 1200 (non-interlace)
Dot clock frequency: 25 MHz to 162 MHz
Scanning frequency | RGB fH: 15–91kHz, fV: 24100 Hz, dot clock: 162 MHz or less
Scanning frequency | YPBPR (YCBCR) 480i (525i): fH 15.73 kHz; fV 59.94 Hz,
576i (625i): fH 15.63 kHz; fV 50 Hz,
480p (525p): fH 31.47 kHz; fV 59.94 Hz,
576p (625p): fH 31.25 kHz; fV 50 Hz,
720 (750)/60p: fH 45.00 kHz; fV 60 Hz,
720 (750)/50p: fH 37.50 kHz; fV 50 Hz,
1080 (1125)/60i: fH 33.75 kHz; fV 60 Hz,
1080 (1125)/50i: fH 28.13 kHz; fV 50 Hz,
1080 (1125)/25p: fH 28.13 kHz; fV 25 Hz,
1080 (1125)/24p: fH 27.00 kHz; fV 24 Hz,
1080 (1125)/24sF: fH 27.00 kHz; fV 48 Hz,
1080 (1125)/30p: fH 33.75 kHz; fV 30 Hz,
1080 (1125)/60p: fH 67.50 kHz; fV 60 Hz,
1080 (1125)/50p: fH 56.25 kHz; fV 50 Hz
Scanning frequency | Video fH: 15.73 kHz / 15.63 kHz fV: 59.94 Hz / 50 Hz
[NTSC/NTSC4.43/PAL/PAL60/PAL-N/PAL-M/SECAM]
Installation CEILING/DESK/AUTO, FRONT/REAR
Speaker 4.0 cm round-type x1
Maximum usable volume output 10 W (monaural)
Optical axis shift Vertical 0 to +40% from center of screen (manual)
U/D ratio 9:1 (when on top end)
Terminals | COMPUTER 1 IN high-density D-Sub 15 p (female)
[RGB signal] R: 0.7 Vp-p ,75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G),
75 ohms, B: 0.7 Vp-p ,75 ohms HD, VD/SYNC: TTL,
high impedance, positive/negative automatic
[YPBPR signal] Y: 1.0 Vp-p (including sync signal),
PB/PR (CB/CR): 0.7 Vp-p, 75 ohms
Terminals | Computer 2 IN/1 OUT high-density D-Sub 15 p (female)
[RGB signal] R: 0.7 Vp-p ,75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G),
75 ohms, B: 0.7 Vp-p ,75 ohms HD, VD/SYNC: TTL,
high impedance, positive/negative automatic
[YPBPR signal] Y: 1.0 Vp-p (including sync signal),
PB/PR (CB/CR): 0.7 Vp-p, 75 ohms
Terminals | VIDEO IN Pin jack 1.0 Vp-p, 75 ohms
Terminals | HDMI 1 IN HDMI 19 pin, HDCP and Deep color compatible
Audio signals : Linear PCM (Sample frequency : 48 kHz/44.1 kHz/32 kHz)
Terminals | HDMI 2 IN HDMI 19 pin, HDCP and Deep color compatible
Audio signals : Linear PCM (Sample frequency : 48 kHz/44.1 kHz/32 kHz)
Terminals | AUDIO IN 1 M3 stereo mini jack, 0.5 V[rms], input impedance 22 k ohms and more
Terminals | AUDIO IN 2 M3 stereo mini jack, 0.5 V[rms], input impedance 22 k ohms and more
Terminals | AUDIO IN 3 Pin jack x 2(L-R), 0.5 V[rms], input impedance 22 k ohms and more
Terminals | VARIABLE AUDIO OUT M3 stereo mini jack, 0 V[rms] to 2.0 V[rms] variable, output impedance
2.2 k ohms and less
Terminals | USB A (DC OUT) USB connector (type A)
Terminals | SERIAL IN D-sub 9 pin, RS-232C compliant, for computer control use
Terminals | LAN RJ-45, for network, PJLink™ compatible, 100Base-TX
Power cord length 3.0 m(9 ft 10 in)(India), 2.0 m(6 ft 7 in)(Other countries)
Cabinet materials Molded plastic
Dimensions (W x H x D) 389 x 125*4 x 332 mm
(15-5/16 x 4-29/32*4 x 13-1/16 in.)
Weight *5 Approx. 4.9 kg (10.8 lb)
Noise level *2 37 dB (LAMP POWER: NORMAL/ECO1), 29 dB (LAMP POWER: ECO2)
Operating Environment | Temperature*6 0°C (32°F) to 40°C (104°F) Elevation: below 1,200 m (3,937')
0°C (32°F) to 30°C (86°F) Elevation: 1,200 m (3,937') – 2,700 m (8,858')
Operating environment | Humidity 20% to 80% (no condensation)

Notes:

*1 When the Standby mode is set to Eco, network functions such as power on over the LAN network will not operate. Also, only certain commands can be received for external control using the serial terminal.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal) for 480i (525i) and 576i (625i)

*4 When adjustable feet shortened.

*5 Average value. May differ depending on models.

*6 If [LAMP POWER] set to [NORMAL], [LAMP MODE] will be switched to [ECO1] automatically when the operating environment temperature is 35°C (95°F) to 40°C (104°F).

Weights and dimensions shown are approximate. Specifications subject to change without notice.

Accessories

Optional Lenses

These lenses install by removing the top cover and 4 screws that hold the standard lens on and then installing a new lens mount.  Add $60 to have the lens mount pre-installed.

Model WD450 WE230 WB210
Zhen Optics WD450 lens Zhen Optics WE230 lens Zhen Optics WB210 lens
D:W
(0.64" WUXGA)
0:38:1 0.52–0.64:1 0.78:1
f/stop 2.1 2.12.2 2.2



Other Accessories

RSMA-UW Chief mount Ceiling mounts
ET-RFV410 Replacement filter (ET-RFV410)
ET-LAV400 lamp Replacement lamp (ET-LAV400)

Downloads

Warranty

3 Years Parts & Labor Warranty; 90 Days Lamp
