NEC PX1004UL-B-18

Laser 1-DLP Projector, 1920x1200 WUXGA, 10,000 Lumens, Standard Lens included, Black, 3 Year Warranty

Item #0601-0032 Model #PX1004ULB18

Features

10,000-lumen Professional Installation Laser Projector w/Lens

Think about projection technology in a whole new light! The NEC PX1004UL is a powerful installation laser projector with a laser/phosphor light source that makes it perfect for all-new applications. This bundle includes th NP18ZL zoom lens. With more consistent brightness, improved color fidelity, and tilt-free or portrait modes these laser projectors will deliver in new verticals such as retail, simulation, and theme park installations. Furthermore, the laser module delivers 20,000 hours of virtually maintenance-free operations, reducing your total cost of ownership!

Bundle includes zoom lens
High-brightness, lower power consumption enhance always-on capabilities of laser projection
Ideal for new applications such as digital signage
Lamp-less operation reduces TCO
Eco-friendly features, minimal maintenance and cost savings mean these laser projectors are still great for demanding integration applications such as higher education and corporate
TileMatrix enables 4Kx2K resolution utilizing digital loop through capabilities
Seamlessly blend multiple images with integrated edge blending capabilities
Built-in HDBaseT enabels simplified installations with a single cable for video, audio, and control signals.

Specifications

Display

Native Resolution	WUXGA 1920 x 1200	Maximum Resolution	4K 4096 x 2160
Contrast Ratio (typical)	10,000:1 with dynamic contrast

Synchronization Range

Horizontal (Analog/Digital)

Analog: 15-100kHz, Digital: 15-153kHz

Vertical

Analog: 48-120Hz, Digital: 24-120Hz

Signal Compatibility/Connectivity

Supported Video Standards	NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM	SD/HD Video Signal Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
PC Signal Compatibility	VGA, SVGA, XGA, SXGA, SXGA+, WXGA, UXGA, FHD, WUXGA, 2K, QXGA, WQXGA, 4k	Macintosh Signal Compatibility	Yes
Sync Compatibility	Separate Sync / Composite Sync / Sync on G	External Control	RS-232, IR, HDBaseT, Stereo Mini, PJ-45
Output Terminals RGB1(analog): VGA 15-pin D-sub RGB2(analog): 5-BNC RGB2(digital): HDMI w/HDCP RGB4(digital): DisplayPort w/HDCP RGB5(digital): HDBaseT Monitor Out: HDMI

Power Consumption (typical)

On	1220W / 625W / 4.3W / 0.2W	Input Current	11.6-5.2A
Power Requirements	100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD)

Net (with stand):

19.7 x 22.9 x 8.5 in. / 500 x 583 x 216mm

Weight

Net Weight (with stand):

63.9 lbs. / 29.0 kg

Environmental Conditions

Operating Temperature

41-104°F / 5-40°C

Storage

-14-122°F / -10-50°C

Limited Warranty (parts & labor)

5 year or 20,000 hour parts & labor warranty. First year InstaCare Service.

Additional Features

Wireless LAN

Cornerstone
Geometric Correction
Auto power on
ECO Mode technology
Virtual Remote
Sleep timer
Quick power-off
Built-in wall color correction
Advanced AccuBlend
AutoSense

Optical

Display Technology	DLP (0.67" DMD)	Light Output(Lumens)	10,000normal
Lamp Type	Laser/Phosphor	Lamp Life (up to)	20,000 hours
Screen Size (diagonal)	40 to 300 in. / 1.02 to 7.62m	Projection Distance	1.5 to 179.8 ft. / 0.5 to 54.8m
Projector Angle	2.1 to 19.1° tele / 3.3 to 24.0° wide	Lens Focus: Power
Keystone Correction	+/- 40° horizontal, +/- 40° vertical

Mechanical

Installation Orientation	Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear	Fan Noise	42 dB normal / 38 dB eco
Regulations	USA: UL(UL60950-1/IEC60825-1 Ed.2), FCC Part15 Class A Canada: C-UL(CSA60950-1/IEC60825-1 Ed.3/IEC62471-5), ICES-003 Class A	Optional Lenses	NP16FL, NP17ZL, NP18ZL, NP19ZL, NP20ZL, NP21ZL, NP31ZL, NP39ZL
