Panasonic TH-65BQ1W

65" 4K UHD Touchscreen Monitor
Item #0601-0260 Model #TH65BQ1W


Panasonic TH-65BQ1W

65" 4K UHD Touchscreen Monitor

The Panasonic TH-65BQ1W is an interactive display that serves as a "teaching and thinking tool".

This touchscreen monitor is compatible with 4K/60p signals and can be used to share high image quality teaching materials and documents. Furthermore, it features convenient functions such as the intuitive white board function. The touchscreen LCD display enables you to easily carry out participatory classes and active meetings.


Touch screen display equipped with new intuitive UI and convenient functions:

A menu bar is displayed on the screen to allow intuitive use. Switching input devices and access to frequently used functions such as the white board drawing tool can be carried out smoothly, supporting effective classes.

Add writing or stamps to documents to make classes easier to understand

  • Easily write with just the display: The BQ1 Series is embedded with a white board function. You can write onto it immediately after turning the power on, reducing the time needed for preparation. It can be operated easily, even by beginner users, thanks to the intuitive UI.
  • Directly write on the displayed images or videos: Directly write images and videos from external input devices such as a PC or projector without the hassle of capturing them. This reduces the time required to draw on a whiteboard.
  • The built-in figures, backgrounds and stamps are useful for classes: Features solid figures and plane figures that can be used for mathematics, and enhanced stamps and backgrounds that can be used for various subjects. Furthermore, images saved to a USB memory can be added as original stamps or backgrounds.
  • Scale up or down teaching materials for increased visibility: Smoothly scale images up or down with a touch. Expand and write on parts that you wish to emphasize, and share teaching materials so that they are easy to see.

Equipped with applications that are convenient for group work

  • The multi-screen comparison function is useful for providing comparative explanations: Captured data or data from a USB memory can be selected and up to nine screens of images can be compared. In addition to comparing samples and opinions during group work, it is possible to freely write or pick up a single-screen display, further deepening understanding among students.
  • A timer function that can be used for group work and tests: Features a wealth of clock functions, including four types of clock, timer, stopwatch and learning clock functions that help achieve time-conscious lessons.

A blue light reduction mode that takes into account eye fatigue

Blue light, which has a short wave length even in visible light and strong energy, is said to have an effect on eye fatigue. The BQ1 Series is equipped with the "blue light reduction" mode, which can reduce up to 53% of the blue light to minimize eye fatigue.*1 This function has acquired*2 the low blue light content certification (No.0235005292) issued by third party certification body TUV Rheinland, which carries out safety testing and certification of industrial products internationally.

Contributes to smooth class progress in various situations

  • The device operation mode lets you operate external devices using a touch panel: Easily switch between the operation of built-in display functions and the operation of external connection devices such as a PC.
  • Screen Transfer function that lets you distribute images to displays in each classroom and conference room: Compatible with the Screen Transfer Ver.2.0 software that shows the PC screen on up to 64 displays via wired LAN. Distribute talks from the headmaster or teacher and the status of in-house training to multiple classrooms and conference rooms, and confirm the distribution status from a PC. By using the priority distribution function, you can distribute images out of order or by automatically turning the power on, enabling you to distribute messages during an emergency.
  • Multi-input display that displays inputs of up to four screens onto a single screen: Display multiple PC screens or different input screens such as images on a PC screen or projector simultaneously.
  • Secondary display function that projects the same patterns even in a large classroom: The display is equipped with a digital output terminal. By connecting a second display or projector with an HDMI cable, images can be projected onto the same screen. Furthermore, comments written onto the screen and scaling can be reflected in real-time, making it convenient for classes held in large classrooms.

Stunning Panasonic 4K Quality Right Down to the Details

With approximately 8,290,000 pixels, or about four times the pixels of a Full-HD display, images are highly detailed. This dynamic, large-screen display archives true-to-life, finely nuanced images. The 4K display is an excellent choice for meeting rooms where images are often viewed up close, and creates impressive ambience in signage applications for commercial facilities.

12-Axis Color Management Archives Faithful Color Reproduction

With the BQ1 Series, the color temperature, shade, and brightness parameters of individual images can be adjusted for red, green, and blue, and their complementary colors, cyan, magenta, and yellow. This keeps the intermediate shades of extremely fine colors vibrant and lifelike.

The IPS Panel Has a Wide Viewing Angle and Reduced Color Changes

There is very little change in color, compared with the VA panel, when the screen is viewed at right or left angles, so the images are crisp and clear. This is ideal for providing correct information to places with a lot of people present, such as public spaces and facilities.

Smooth Switching of Presenters

The BQ1 Series detects the signal when the display and PC are connected with a video cable*3, and activates the following chain of operations: display power ON → input switched → display power OFF. Without requiring remote control operation, a presenter can smoothly switch the PC screen, without worrying about forgetting to turn off the power when the meeting ends.

The Display Has a Built-in 4K Compatible USB Media Player

By simply inserting a USB memory stick onto which content has been saved, playback automatically starts. Since it is 4K compatible, it easily provides 4K digital signage without having to use a PC or set-top box. Content can be consecutively played*4 without letterboxing. Content can also be switched via LAN or multiple displays can be operated.

Applicable format

Still Image JPG, JPEG, JPE, BMP
Motion Image AVI, MKV, WMV, ASF, MP4, MOV, FLV, TS, MTS

Supports the Next-Generation Intel® SDM Specification Slot Standard

The BQ1 Series is equipped with the new Intel® SDM specification slot standard that supports 4K signals. Combined with the interface board*5, you can easily use a built-in PC and add various interfaces.

Multi Monitoring & Control Software

Compatible with Multi Monitoring & Control Software for addition of new functions, such as automatic searching for map displays and registered devices. Displays and peripheral equipment on the intranet can be controlled and their status can be monitored. As well, error notification and error indication can be detected by an indication monitoring function (for a fee) for improved maintenance.

Failover and Failback Safeguards for Mission Critical Situations

If the main video and audio signals are interrupted, the system immediately switches to alternative signals. If the main signals are restored, the original image is displayed*6. This makes it ideal for mission critical control rooms and surveillance centers.

Other functions

  • Calculator function
  • Video mask function
  • Sound Adjustment for Conference Room
  • Whiteboard Software


*1: Effects are not guaranteed. Authentication information:

*2: Video menu: Graphics, blue light reduction: When set to high

*3 Compatible terminals are HDMI1/HDMI2/DVI-D/PC. The Power Management of the display itself must be set in advance. Effective terminals depend on menu settings.

*4 Some files cannot be played back even if they are in the supported format. Regarding restrictions, see the operation manual.

*5 Third-party Intel® SDM-specified function boards sold separately. Panasonic cannot guarantee operation of third-party devices. The transmission method to the slot must be by HDMI™ signal.

*6 The usable combinations of main and backup signals are limited.



Screen Size (diagonal) 65-inch (64.5" / 1638.9 mm)
Aspect Ratio 16:9
Effective Display Area (W x H) 1428.4 x 803.5 mm (56.2" x 31.6" )
Resolution (H x V) 3840 x 2160
Brightness*1 500 cd/m²
Contrast Ratio 1200:1
Response Time 8.0 ms (G to G)
Viewing Angle 178° / 178° (CR > 10)

Touch Panel

Detection Method Infrared blocking detection method
Touch Operation Up to 20-point multi-touch*2
OS Windows® (8.1/10),
Mac OS X (10.10/10.11), macOS (10.12/10.13/10.14/10.15/11.0)

Connection Terminal

HDMI In Type A Connector x 3 (HDCP 2.2 supported)
DIGITAL Out HDMI Type A Connector x 1
DisplayPort In DisplayPort x 1 (HDCP 2.2 supported)
DVI-D In DVI-D 24-pin x 1
PC In Mini D-Sub 15-pin x1 (compatible with DDC2B)
USB*3 USB TYPE A Connector (female) x 1 DC5 V/ 0.9 A, (USB3.0 supported.) : Back
USB TYPE A Connector (female) x 2 DC5 V/ 0.5 A, (USB2.0 supported.) : Front
USB (TOUCH) USB TYPE B Connector (male) x 1
Serial In D-Sub 9-pin x 1 (for external control, RS-232C compliant)
Audio In Stereo mini-jack (M3) x 2 (Shared with DCI-D IN and PC IN)
Audio Out Stereo mini-jack (M3) x 1
LAN RJ45 x 1, 10BASE-T/ 100BASE-TX/1000BASE-T, compatible with PJLink™
SLOT Intel® SDM specification
Corresponding size SDM-S / SDM-L, Supply power 3.3 V / 1.1 A, 12 V / 5.5 A


Built-in speaker 20 W (10 W + 10 W) 10% THD
Speaker Out 30 W (15 W + 15 W) 10% THD


Power Requirements 110-240 AC, 50 / 60 Hz
Power Consumption 320 W
On Mode Average Power Consumption*4 230 W
Power Off Condition Approx. 0.3 W
Standby Condition Approx. 0.5 W


Dimensions (W x H x D) 1495 x 908 x 105 mm
(58.9" x 35.8" x 4.2")
(with handles)
Bezel Width T/R/L 16.3 mm (0.64")
B 54.3 mm (2.14") (with speaker)
Weight 43.4 kg (95.7 lb)
Pitch for Wall-hanging VESA Compliant 400 x 400 mm (15.8" x 15.8")
Protective Glass Anti Glare Surface / Scattering prevention film

Installation Requirement*5

Orientation Landscape / Portrait
Tilting Angle Landscape: 0 degrees forward, 0-45 degrees backward, Portrait: 0 degrees forward/backward


Operating Environment Temperature: 0 °C to 40 °C (32 °F to 104 °F)
[for up to 1400 m (4593') altitude] / 0 °C to 35 °C (32 °F to 95 °F)
[for between 1400 m and 2800 m (4593' and 9186') altitude],
Humidity: 20 % to 80 % (Non-condensation)
Operating Time*6 18 h/day


*1: The brightness of display panel not shipping product.

*2: When using the Whiteboard Software for Windows®. When using Mac is single touch.

*3: Multiple USB Terminals can not be used at the same time by switching the input signal.

*4: Based on IEC 62087 Ed.2 measurement method.

*5: Please contact your sales representative with regard to the tilt angle before installation.

*6: If you display a still picture for an extended period, the image retention might remain on the screen. However, image retention can gradually disappear by displaying a moving image.



1. Interactive meeting in hybrid environment (Device Operation Mode)


2. Easy internal video steaming and signage solution (Screen Transfer function)
