Optoma EH504WIFI

DLP Projector, 1920x1080, 5000 Lumens, Vertical Lens Shift, Includes HDCastPro WiFi, D:W 1.41-2.24:1, 3 Year Warranty
Item #0601-3731 Model #EH504WIFI


Full HD Professional Installation DLP Projector
  • Wireless ready for screen mirroring and 4-way split screen presentation
  • Bright Projection - 5000 ANSI lumens
  • Four Corner correction - For a quick installation onto uneven walls
  • Installation flexibility – Vertical lens shift and 1.6x zoom
  • Full Control over LAN and RS232
  • Vertical and Horizontal Keystone
The Optoma EH504WIFI is a full HD 1080p professional installation projector, offering a brightness of 5000 lumens, crystal clear images, and a variety of advanced features to facilitate a quick installation. The Optoma EH504WIFI is ideal for conference rooms, large classrooms, lecture theatres, museums and houses of worship.
For more complex installations, this projector is equipped with a large zoom range, vertical lens shift and a built-in geometric adjustment feature - ideal for uneven walls or where a projector placement is awkward and needs to be installed at an angle.


EH504WIFI Specification

Display Technology Single 0.65” 1080p chip, DLP® Technology from Texas Instruments™
Native Resolution 1080p 1920 x 1080
Brightness 5000 Lumens
Contrast Ratio 15000:1
Lamp Life (hrs)
Throw Ratio 1.41~2.24:1 (distance/width)
Keystone Correction ±30° Vertical and Horizontal
Weight 10.2 lb (4.6 kg)
Dimensions (W x H x D) 14.5" x 12" x 5.2"
Aspect Ratio 16:9 (native), 4:3, Auto
Offset 99% to 116% (+/- 5% variance)
Projection Screen Size 26.2"~301.1" (diagonal)
Projection Distance 51.18"–370"
Projection Lens F=2.5~3.26, f=20.913~32.626mm - manual zoom and focus
Uniformity 70%
Maximum Resolution 1080p (1920 x 1080)
Computer Compatibility UXGA, SXGA, XGA, SVGA, VGA, WXGA,1080p, Mac
Video Compatibility PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25,MHz, 4.4MHz, 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz) 1080p(24/50/60Hz)
3D Compatibility Side-by-Side:1080i50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
Horizontal Scan Rate 15.375–91.146 KHz
Vertical Scan Rate 24–85 Hz (120 Hz for 3D feature projector)
Displayable Colors 1.07 Billion
Power Supply AC input 100–240V, 50–60 Hz, auto-switching
Power Consumption 421W Max (Bright), 329W Max (ECO)
Operating Conditions Operating Temp @ Sea Level to 10000 feet = 23°C (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)
Remote Control SP.72702GC01
Optional Wireless No
Warranty 3 Years
Projection method Front, rear, ceiling mount, table top
Warranty 3-Year Optoma Express Service, 1-Year on Lamp
