Eiki C735
7,300 Center Lumens WUXGA 3LCD Laser Projector
The Eiki C735 projector is designed with the most advanced technology for durability and ease of use. This projector features a Laser Phosphor light source with 7,300 center lumens of brightness and WUXGA resolution, built-in multimedia features, a palette of 1.07 billion colors, and matrix liquid crystal display (LCD) technology.
The C735 supports analog and digital video input in all color standards up to 1080p, and 4K video input via HDMI. In addition, it features 5,000,000:1 dynamic contrast ratio as well as horizontal and vertical manual lens shift, keystone correction, and geometric correction for flexible installation.
This large venue projector comes with a 1.6x manual zoom lens with 1.2-2.0:1 throw ratio. It is compatible with Crestron RoomView and AMX Device Discovery technology.
Note: Unlike the C735P and C735PS models, the C735 doesn't feature 4K pixel-shifting technology.
Features
- 7,300 center lumens brightness with 80% uniformity and a 5,000,000:1 contrast ratio.
- Native WUXGA resolution; compatible with inputs up to UXGA, WUXGA and 4K.
- Compatible with inputs up to 1080p, WUXGA and 4K. HDR10 support.
- High brightness and contrast with long life 20,000-hour Laser + Phosphor Light Source.
- 10-bit color processing for superior color reproduction.
-
Convenient mid-range 1.6x manual zoom and focus lens with 1.2-2.0:1 throw ratio.
- Supports analog and digital video input in all color standards up to 1080p.
- Supports 4K (3840x2160 @ 60 Hz) video input via HDMI.
- Horizontal, Vertical & Corner Keystone Correction.
- Pincushion/Barrel & 6-point Geometric Correction.
- Horizontal & Vertical Manual Lens Shift. Wired network control.
- 360° free orientation
- Displays 4:3, 16:9 and 16:10 aspect ratios. Supports most HDTV resolutions.
- Built-in 16-watt amplifier and speaker system. Closed Caption decoding.
- Side-accessed air filter for ease of maintenance.
- Auto input selection. Built-in Test Patterns.
- Security bar. Kensington® MicroSaver® security slot. PIN lock.
- Compatible with Crestron™ RoomView and AMX Device Discovery Technology
- 3-year projector warranty. 20,000 hour Laser Light Engine warranty.
Specifications
| Display Type |
0.64" (16 mm) inorganic LCD Panels x 3 |
||
|---|---|---|---|
| Resolution |
WUXGA (1920 x 1200) |
||
| Aspect Ratio |
16:10 |
||
| Brightness | 7,300 Center Lumens (approx. 6600 ANSI Lumens) | ||
| Contrast Ratio |
5,000,000:1 |
||
| Projection Light Source |
Laser (Blue) + Phosphor |
||
| Light Source Life |
20,000 hours |
||
| Image Diagonal |
30–300 in (76.2–762 cm) |
||
|
LENS |
F Value / Focal Length |
f: 1.5–2.08 |
|
| Zoom Ratio |
Manual x1.6 |
||
| Focus |
Manual |
||
| Throw Ratio |
1.2–2.0:1 |
||
| Throw Distance |
2.5–42.0 ft (0.77–12.8 m) |
||
| Lens Shift |
V: +60% H: ±29% (Manual) |
||
| Keystone Correction |
V: ±30°, H: ±30°, Corner Keystone |
||
| Projection Elevation Adjustment |
up to 3.5° |
||
| Scanning Frequency |
H Sync. 15–135 KHz, V Sync. 24–85 Hz |
||
| Pixel Clock |
up to 160 MHz |
||
| TERMINALS | |||
| HDBaseT In |
RJ45 x 1 |
||
| VGA In |
Dsub15 x 1 |
||
| HDMI In |
HDMI x 2 |
||
| RS-232 |
Dsub9 x 1 |
||
| USB |
USB Type A x 1 (Memory Viewer) |
||
| USB |
USB Type B x 2 (Firmware) |
||
| VGA Out | Dsub15 x 1 | ||
| LAN |
RJ45 x 1 |
||
| Audio In | 3.5 mm MiniStereo x 1 | ||
| Audio Out |
3.5 mm MiniStereo x 1 |
||
| Speaker |
Mono 16 Watt |
||
| Fan Noise (Eco/Normal) |
29 dB / 39 dB |
||
| Dimensions (H x W x D) |
5.4" x 15.9" x 14.1" (13.7 x 40.5 x 35.8 cm) excluding legs |
||
| Weight |
17.4 lb (7.9 kg) |
||
| Power Requirements |
100–240 V AC, 50/60 Hz |
||
| Power Consumption |
0.5 W in Eco Standby mode, up to 425 W |
||
| Thermal Dissipation |
1,450 BTU |
||
| Included (Standard) Accessories |
|
||
| Optional Accessories |
|
||
Warranty
Projector: 3-year/6000-hour limited warranty (whichever occurs first)
Laser Light Engine: 3 years/20,000 hours use (whichever occurs first)
