Vivitek DU7295Z-WH

Laser DLP Projector, WUXGA, 9000 Lumens, No Lens, White
Part #: 0601-8393    Mfr #: DU7295ZWH

Vivitek DU7295Z-WH

Overview

Vivitek DU7295Z-WH

Bright 9,000 Lumens WUXGA laser projector

Widely regarded as the future of professional and consumer projection technology, laser projectors possess numerous advantages over traditional lamp-based systems. From enhanced brightness to minimal costs of ownership, laser projectors have quickly become the optimal projection choice for a diverse range of applications.

The DU7295Z-WH is a smart choice for mid to large corporate meeting rooms, houses of worship, and professional installations, thanks to its low total cost of ownership. This laser projector packs tremendous value for companies seeking maintenance-free durability up to 20,000 hours with easy installation and management.

Ensuring superior visibility with 9,000 ANSI lumen brightness and vibrant true-to-life colors with Rec. 709 color space, the DU7295Z-WH also offers exceptionally quiet 35 dB operation. Furthermore, it can be complemented with Vivitek’s NovoConnect Solution for wireless presentation and collaboration.

The DU7295Z-WH comes with a white casing and does not include a lens.

Features

  • Advanced laser phosphor light engine for superior brightness and color uniformity
  • Lampless design delivers up to 20,000 hours of operational time
  • Up to 9,000 ANSI lumens with a 20,000:1 contrast ratio
  • Native WUXGA resolution with a maximum WUXGA resolution
  • Manual zoom and focus for easy adjustment and positioning flexibility
  • Centered lens for easy installation
  • Horizontal and vertical lens shift for greater installation convenience and flexibility
  • Distorted and trapezoid image issues are easily corrected with keystone, and 4-corner adjustment
  • HDBaseT™ interface with support for distribution of HD video and digital audio content over standard CAT5e/6 LAN cable
  • Full suite of connectivity ports including: HDMI v2, DVI-D, Composite Video, Component (5 BNC) (RGBHV), VGA-In/Out, HDBaseT™ , LAN, RS-232-In/Out
  • Total 20 W (10 W x 2) audio speaker power with multiple audio-in and audio-out ports
  • 3D sync port for compatibility with IR (infrared) 3D passive synchronization protocol
  • 360° (degree) installation for flexible installation in a wide variety of environmental conditions
  • Network ready for integration and system administration via RJ45
  • Crestron® RoomView™ integration for network monitoring and management
  • Seven (7) interchangeable lens options with quick touch lens release design for easy lens installation/removal
  • Anti-theft security features include: Kensington® security slot, and security bar
  • Minimal required maintenance thanks to an instantaneous power-on and off, a sealed optical engine, and an airflow-optimized system layout.

Specifications

Display Type Single Chip 0.67" DLP Technology by TI
Brightness 9,000 ANSI Lumens
Native Resolution WUXGA (1920 x 1200)
Maximum Resolution WUXGA (1920 x 1200) @60Hz
Contrast Ratio 20,000:1
Laser Life/Type 20,000+ hours (Laser Phosphor Light Engine)
Throw Ratio* 1.54 – 1.93:1
Image Size (Diagonal)* 36.1"  211"
Projection Distance* 1.5 m  7 m (4.9 ft  22.96 ft)
Projection Lens* F# = 2.0 ~ 2.09
f = 22.8  28.5 mm
Zoom Ratio* 1.25x
Aspect Ratio 16:10
Offset N/A (Manual Focus/Zoom)
Keystone Correction Vertical: ±25°  ±30°, Horizontal: ±30°
Horizontal Frequency 15, 31  91.4 Hz
Vertical Scan Rate 24  30 Hz, 47  120 Hz
3D Yes (DLP® Link™, HDMI 1.4 (Blu-Ray 3D)
Speaker 10 W (x2)
Lens Shift Range* Vertical: -15% to +55%, Horizontal: -5% to +5%
Computer Compatibility VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA,4K@60hz, Mac
Video Compatibility SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L)
I/O Connection Ports HDMI v2 (x2), DVI-D, Composite Video, Component (5 BNC) (RGBHV), 3D-Sync-In, VGA-In, Audio-In RCA (L/R), Audio-In (Mini-Jack), VGA-Out, AudioOut RCA (L/R), 3D Sync-Out, USB Type A Power (5V/1.5A), 3D-Sync-Out, 12V Trigger, RS-232-In, RS232-Out, Wired Remote-In, Wired Remote-Out, HDBaseT™, RJ45 (LAN), USB (Service)
Projection Method Table Top, Ceiling Mount (Front or Rear)
Security Solutions Kensington® Security Slot, Security Bar, Keypad Lock
Dimensions (W x D x H) 470 x 517 x 202 mm (18.5” x 20.3” x 7.9")
Weight 24.5 kg (54 lbs)
Color White
Noise Level 37 dB / 35 dB (Normal/Eco. Mode)
Power Supply AC 100240 V, 50/60 Hz
Power Consumption 690 W (Normal Mode), 560 W (Eco. Mode),
Standard Accessories AC Power Cord, VGA Cable, Remote Control, Filter, Lens Cap, Documentation Kit
Optional Accessories Interchangeable Lens Options (x7). See Accessories tab.
Standard Warranty 5-Year Warranty on Parts and Labor / 3 years Advanced Exchange / 1-year Lamp Warranty



*Overdrive

Accessories

Optional Lenses

Model VL904G VL911G VL907G VL912G VL906G
Std Lens
VL908G VL909G
Price $798.00
Add to Cart
$1,306.00
Add to Cart
$1,169.00
Add to Cart
$1,224.00
Add to Cart
$385.00
Add to Cart
$990.00
Add to Cart
$1,224.00
Add to Cart
VL904G VL911G VL907G VL912G VL906G VL908G VL909G
D:W
WUXGA
0.78:1 0.77 – 1.1:1 1.1 – 1.3:1 1.25 – 1.60:1 1.54 - 1.93:1 1.93 – 2.9:1 3.0 – 5.0:1
F/stop 2.54 2.1 – 2.6 2.05 – 2.27 2.0 – 2.44 2.0 – 2.09 2.5 – 3.1 2.2  2.5



Other Accessories

Chief VCT-UW Ceiling mounts
