ViewSonic LS740HD

Laser DLP Projector, 1080p, 5000 Lumens, D:W 1.13-1.47:1, 3-Year Warranty
Item #0601-8917 Model #LS740HD
$1,049.00
Price

Overview

ViewSonic LS740HD

5,000 ANSI Lumens 1080p Laser Projector

With the ViewSonic® LS740HD laser projector, you can light up every room with brilliant presentations and razor-sharp resolution. Featuring the latest laser phosphor technology, the LS740HD projector delivers 5,000 ANSI lumens of brightness to ensure crisp images even in rooms with ambient lighting.

Enjoy a maintenance-free projection experience without having to deal with complicated lamp replacements. This eco-friendly projection solution features a compact design for easier transportation. Experience screen sizes up to 300" in 1080p Full HD resolution for show-stopping images designed to fill up boardrooms, lecture halls, auditoriums and other public spaces.

The LS740HD laser projector comes loaded with features like 1.3x optical zoom, H/V keystone, 4-corner adjustment, 360° projection and portrait mode for easy setup and versatile applications.



Key Features:
  • High brightness 5000 Lumens 1080p laser projector with advanced visual features
  • Long-lasting laser phosphor light source allows the lamp to shine bright for up to 30,000 hours
  • 1.3x optical zoom, 360-degree projection, H/V keystone, and 4-corner adjustment
  • This projector can be configured to automatically turn on and off
  • Schedule and manage the projector remotely with Crestron, AMX, Extron, PJ Link, ATEN, and ViewSonic's vController
  • Supports most media players, PCs, Macs, and mobile devices with inputs such as HDMI and USB Type A



Features

  • 3rd-Generation Laser Phosphor Technology: The LS740HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.

  • 5,000 ANSI Lumens of Brightness: Delivering 5,000 ANSI Lumens, the LS740HD provides vibrant and sharp projection in 1080p FHD in all lighting conditions for auditoriums, boardrooms, public venues, and other expansive spaces.

  • High Native Contrast Ratio: Achieved through its Texas Instruments 0.65" DMD chip, the projector's high native contrast ratio enables deeper blacks and brighter whites. As a result, it delivers more visual depth, clearer images, and enhanced legibility.

  • Ultra-large Screen up tp 300": This easy-to-install projector allows for an image size of up to 300", offering a lower cost-per-inch compared to other types of commercial displays.

  • Light Weight, Compact Size: The LS740HD is 35% lighter in weight and 35% smaller in size compared to its predecessor and even most competing projectors in the market, greatly reducing the cost of transportation and increasing the ease of installation.
  • Lower Power Consumption than Competitors: With its advanced lamp-free light source, the LS740HD offers a highly energy-efficient and cost-saving display solution by consuming up to 51% less power than competing projectors.
  • 1.3x Optical Zoom: allows users to choose the most ideal setup location within a range, getting the desired image size without needing to change the existing interior design.
  • Horizontal/Vertical Keystone Correction and 4-Corner Adjustment: eliminate crooked or distorted images for a perfectly proportioned picture every time.
  • 360° Projection and 90° Portrait Mode: The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors. Its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
  • ViewSonic’s Exclusive Color Technology: will impress any audience by elevating your presentation with a true-to-life color experience.

  • Non-stop 24/7 Operation: The projector's advanced cooling design enables 24/7 operation without any degradation in image quality or performance. This makes it the go-to solution for applications that require continuous projection in retail stores, malls, museums, airports, and other public spaces.

  • Simpler Way to Update Projector Software: Skip trips to the service center by keeping software up to date easily via USB cable connection with your own laptop.

  • USB-A Power Supply: The built-in 5V/1.5A USB-A output conveniently delivers power to a wireless HDMI dongle, eliminating the need for separate power adapters when streaming multi media content.
  • IP6X Enhanced Dust Resistance: Maintain crystal-clear image quality and product longevity with an advanced IP6X sealed engine design that prevents dust from entering and affecting internal components.

Specifications

Display:

Screen Size: 30–300 in. / 0.76–7.62 m
Throw Distance:

1–8 m (100" @ 2.50 m)
Throw Ratio:  1.13~1.47:1
Lens: 1.3x optical zoom
Light Source: Laser
Light Source Life: Normal: 20,000 hours
Dynamic Eco-Mode: 30,000 hours
Color Depth:  1.07 Billion Colors
Input Lag: 37 ms
Display Resolution:  Full HD (1920x1080)
Brightness: 5,000 ANSI Lumens
Dynamic Contrast Ratio:  3,000,000:1
Aspect Ratio: 16:9
Keystone:  Vertical: ±19º / Horizontal:±19º

Video Signal:

Frequency Horizontal: 15 – 102 KHz
Frequency Vertical: 24 – 120 Hz

Compatibility:

PC Resolution (max): VGA (640 x 480) to WUXGA RB (1920 x 1200)
Mac® Resolution (max): 480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Connector:

  • USB 2.0 Type A: 1
  • 3.5 mm Audio Out: 1
  • Control (RS232): 1
  • HDMI 1.4 (with HDCP 1.4): 2

Audio:

Internal Speakers: 15 W (x1)

Power:

Voltage: 100–240 V ±10%, 50/60 Hz AC
Consumption (typical): 210 W
Stand-by: < 0.5 W

Controls:

Physical Controls: Keypad, Power key
On Screen Display: Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality)
Remote: Yes

Operating Conditions:

Temperature: 32–104º F (0–40º C)

Additional Hardware:

Kensington Lock Slot: 1

Weight:

Net: 6.6 lb (3.0 kg)
Gross: 10.4 lb (4.7 kg)

Dimensions (WxHxD):

Packaging: 15.7 x 11 x 6.1 in (400 x 280 x 155 mm)
Physical: 11.3 x 8.5 x 5 in (286 x 216 x 129 mm)

Warranty:

Three-year limited warranty on parts and labor, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration).

What's in the box:

  • LS740HD projector
  • Power cable
  • Remote control
  • Quick Start Guide
