LCD Projector, Laser Light Source, 1920x1200 WUXGA, 7000 Lumens, No Lens, Black Case, 5 year or 12,000 Hr. warranty
Part #: 0602-6000    Mfr #: VPLFHZ700LB




The VPL-FHZ700L combines exceptional picture quality and brightness with the reliability, extended operating life and reduced running costs of laser projection.

Delivering crisp, brighter images with a class-leading 7,000 lumens brightness, the VPL-FHZ700L features a powerful, highly efficient laser light source that offers a nominal 20,000* hours operating time.

With no waiting time for lamps to warm up or cool down, switching on/off is virtually instantaneous. Together with the long-life 3LCD panel and advanced filter system, the laser light source cuts the need for regular maintenance visits. There’s also a range of energy-saving features that contribute to a reduction in lifetime ownership costs compared with conventional projectors.

Its high brightness and minimal maintenance needs make the VPL-FHZ700L a compelling presentation choice in a wide range of applications – from boardrooms and lecture theatres to museums, exhibitions and retail spaces.

Installer-friendly features like free-angle installation and edge blending also assist with integration into a wide range of corporate, educational, public sector and entertainment environments.

* With Auto Light Dimming feature enabled. Actual hours may vary depending on usage.


  • Laser light source projector with Sony 3LCD BrightEra™ Panel Technology

    The VPL-FHZ700L combines a highly efficient laser light source with Sony’s advanced 3LCD BrightEra™ technology. This unique combination delivers exceptionally bright, pictures with excellent colour accuracy and stability, plus high efficiency and significantly greater durability for reduced total cost of ownership.

  • Clear, bright, punchy presentations in any lighting conditions

    Add more detail, impact and realism to presentations with very high 7000 lumen brightness. Get your message across in large boardrooms, auditoriums or retail spaces even when ambient light levels are high.

  • Crisp, detail-packed WUXGA resolution images

    See the finest detail in PC presentations, videos or multimedia signage with WUXGA (1920 x 1200) 16:10 resolution.

  • Up to 20,000* hours operation with virtually no maintenance

    The advanced laser light source offers a typical 20,000 hours operation without maintenance or replacement, reducing lifetime running costs compared with traditional projectors. 20,000 hours filter replacement cycles keep the projector in peak operating condition while reducing maintenance trips even further.

  • Wide range of Lens Shift, Zoom, Throw Ratio

    Generous zoom, throw and lens shift adjustments give more flexibility for positioning the projector where you need it: close to ceilings, near the screen or even horizontally offset. Extend throw ratio even further with a choice of optional lenses.

  • 360° free-angle installation capability

    Enjoy supreme installation flexibility: position the projector freely at any angle – or its side or even upside down.

  • Connectivity via HDBaseT™

    The projector allows simple connectivity using an HDBaseT digital interface, multi signal transmission system, providing a single cable, cost-effective, long-distance, and high-quality digital transmission solution.

  • Create super-size displays with Edge Blending

    Seamlessly join accurately colour-matched images from multiple projectors, simplifying creation of stunning super-size displays for retail, corporate and live event applications.

  • Project onto non-flat surfaces with Image Warping

    Easily correct image geometry for natural-looking projections – even on convex or concave surfaces. Corner and edge correction can be easily adjusted with the supplied remote and on-screen menu.

  • Advanced energy-saving features

    Advanced light source and control technology enables robust energy-saving features. Greater brightness control in Auto Dimming mode saves considerable energy when the projector is left on without being used. During projection, Auto Light output Mode automatically adjusts light output to suit the projected scene. When you need to mute the picture temporarily, light output can be completely deactivated to minimise energy consumption.

    *1. With Auto Light Dimming feature enabled. Actual hours may vary depending on usage.
    *2. HDBaseT™ and the HDBaseT Alliance logo are trademarks of the HDBaseT Alliance.



Model: VPLL-Z4007 VPLL-4008 VPLL-Z4011 VPLL-ZM42  VPLL-Z4015  VPLL-Z4019  VPLL-Z4025  VPLL-Z4045
  VPLL-Z4007 VPLL-4008 VPLL-Z4011  PK-F500LA2 VPLL-Z4015 VPLL-Z4019 VPLL-Z4025 VPLL-Z4045
D:W 0.68:1 - 0.80:1 1.08:1 1.38:1 - 2.06:1 1.83-2.28:1 2.02:1 - 2.67:1 2.62:1 to 3.36:1  3.30:1 - 6.11:1  6.08:1 - 10.52:1
f-Stop: 1.85-2.10 2.00 1.75-2.40 1.74-2.28 2.20-2.60 1.70-2.10 2.20-3.10 2.20-3.60
Adapter: - - - PK-F500LA2 - - - -
Compensator: Remove Installed (default) Remove Remove Installed (default) Installed (default) Installed (default) Installed (default)


Other Accessories



HDBaseT Interface Adaptor



3G-SDI Input Adaptor


Sony VPL-FHZ700LB Warranty

Factory 5 Year or 12,000 Hours, whichever comes first.
