Eiki EK-55LU
Overview
Eiki EK-55LU
5500 Center Lumens WUXGA 3LCD Ultra Short Throw Laser Projector
The Eiki EK-55LU is a native WUXGA 3LCD projector that features 5,500 center lumens of brightness with 80% uniformity and a 5,000,000:1 contrast ratio.
It supports analog and digital video input in all color standards up to 1080p, as well as 4K video input via HDMI. The Eiki EK-55LU projector features horizontal, vertical, and corner keystone correction, pincushion/barrel, and 6-point geometric correction.
It also sports an ultra short throw (0.235:1) manual focus lens.
Features
- 5,500 center lumens bright with 80% uniformity and a 5,000,000:1 contrast ratio
- High brightness and contrast with long life 20,000-hour laser light source
- Ultra short throw (0.235:1) manual focus lens
- 10-bit color processing, for superior color reproduction
- Native WUXGA resolution. Compatible with inputs up to UXGA, WUXGA and 4K
- Supports 4K video input via HDMI
-
Supports analog and digital video input in all color standards up to 1080p.
- Horizontal, Vertical, and Corner Keystone Correction
- Pincushion/Barrel & 6 point Geometric Correction
- Built-in 16-watt amplifier and speaker sound system. Closed Caption decoding (NTSC)
- Compatible with Crestron RoomView™ and AMX Device Discovery Technology
- Wired network control and monitoring
-
Displays 4:3, 16:9 and 16:10 aspect ratios. Supports most HDTV resolutions.
-
Rear-accessed air filter for ease of maintenance.
-
Auto input selection. Built-in Test Patterns.
-
Security bar. Kensington® MicroSaver® security slot. PIN lock.
Specifications
| Display Type |
0.64" 3LCD |
||
|---|---|---|---|
| Resolution |
WUXGA (1920 x 1200) |
||
| Aspect Ratio |
16:10 |
||
| Brightness | 5,500 Center Lumens | ||
| Contrast Ratio |
5,000,000:1 |
||
| Projection Light Source |
Laser |
||
| Light Source Life |
20,000 hours |
||
| Image Diagonal |
80–120" |
||
|
LENS |
Type |
Manual focus, fixed lens |
|
| F Value |
1.7 |
||
| Focal Length |
0.115 in (2.94 mm) |
||
| Throw Ratio |
0.235:1 |
||
| Throw Distance |
1.34–2.0 ft (0.41–0.61 m) |
||
| Keystone Correction |
V: ±5° H: ±5°, Corner Keystone |
||
| Projection Elevation Adjustment |
up to 2° |
||
| Scanning Frequency |
H Sync. 15–100 KHz, V Sync. 24–85 Hz |
||
| Dot Clock |
up to 300 MHz |
||
| Input Signals - Computer |
4K (3840 x 2160) – VGA (640 x 480) |
||
| Input Signals - Video |
1080 i/p, 720 p, 576 i/p, 480 i/p |
||
| TERMINALS | |||
| HDMI In |
HDMI x 2 |
||
| VGA In |
Dsub15 x 1 |
||
| VGA Out |
Dsub15 x 1 |
||
| USB |
USB Type A x 1 (Memory Viewer) |
||
| USB |
USB Type B x 2 (Firmware) |
||
| Audio In |
3.5 mm MiniStereo x 1 |
||
| Audio Out |
3.5 mm MiniStereo x 1 |
||
| Built-in Speaker |
Mono 16 Watts |
||
| Fan Noise (Eco/Normal) |
27 dB / 37 dB |
||
| Dimensions (H x W x D) |
6.6 x 20.5 x 17.6 in (16.8 x 52.1 x 44.6 cm) |
||
| Weight |
24 lb (11 kg) |
||
| Power Requirements |
100–240V AC, 50/60 Hz |
||
| Power Consumption |
0.5 W in Eco Standby mode, up to 380 W |
||
| Thermal Dissipation |
1297 BTU |
||
| Standard Accessories |
|
||
Limited Warranty
To the original end use customer only
- Projector: 3 years or 6,000 hours, whichever occurs first
- Laser Light Engine only: 20,000 hours of use
