Epson PowerLite 800F

Laser LCD Projector, 1366x768 native, 4096x2160 max input, 5000 Lumens, 0.27:1 UST, 130" max image, 3-year warranty
Item #0600-4270 Model #V11H923520

Overview

Epson PowerLite 800F

5000 Lumens Ultra Short-throw Laser Projector for Classrooms

Create dynamic, captivating classroom displays with the PowerLite 800F ultra short-throw laser projector. Offering 5,000 lumens of brightness and 1366 x 768 native resolution (1080 vertical resolution with pixel shifting), this versatile projector provides large, true-to-life images up to 130" (16:9) for easy reading from nearly anywhere. Or use the built-in edge blend feature for an even larger than life experience.

A durable and flexible solution, the PowerLite 800F provides ultra short-throw technology for convenient projection in small spaces and includes a virtually maintenance free 20,000-hour optical laser light source engine with no lamps to replace, for lasting reliability.

Presenting a variety of connectivity options, optional wireless, and a built-in speaker, the PowerLite 800F offers the features you need to deliver lesson plans with engaging, immersive content on nearly any flat surface.



Key Features:
  • 5,000 lumens of color and white brightness
  • 1366 x 768 native resolution, 1080 vertical resolution with pixel shifting
  • Projects up to 130" (16:9) diagonal
  • 20,000-hour laser light engine with no lamps
  • Convenient ultra short-throw design
  • HDMI, HDBaseT and wireless connectivity
  • Built-in edge blending and split screen features for easy, scalable projection
  • Content management software and creative content app for easy creation and management of content for digital signage

The PowerLite 800F is a white projector. (The black model is PowerLite 805F.)

(Model:V11H923520)

Features

Bright, high-resolution projection system

  • Up to 5000 lumens of color brightness (color light output) and white brightness (white light output)1
  • 1366 x 768 native resolution, 1080 vertical resolution with pixel shifting

Flexible connectivity

  • Three HDMI ports for computer or video device connection
  • Plug-and-play USB projection and audio for instant setup
  • Optional HDBaseT control pad with single connection to projector for simplified cabling and installation
  • Wired and wireless (optional accessory required) network support for projection
  • Screen mirroring to connect your mobile device wirelessly using Miracast technology (optional accessory may be required)
  • Projector monitoring and control via remote network computer
  • PC-free photo slide shows via connected USB memory devices or Epson document camera (only on models that support the slide show function)
  • One HDMI Out port for connecting an external display or linking another compatible projector
  • Use Epson iProjection (Windows/Mac) to simultaneously project up to four images from network computers or mobile devices (optional accessory may be required)
  • Projection from an iOS device, Android device, or Chromebook with the free Epson iProjection app.(Optional accessory may be required.)

Innovative display and operation features

  • Long-life laser light source
  • Easy-to-use and free content management software for creating amazing effects and experiences for digital signage
  • Support for side-by-side projector mounting
  • High digital zoom ratio for larger images in shorter projection distances (ultra short throw ratio of 0.27:1)
  • 2,500,000:1 dynamic contrast ratio and Dynamic Contrast control for sharp, detailed images
  • Built-in closed captioning decoder
  • Powerful 16 W (2 x 8 W) speaker system with audio out port for connecting external speakers
  • Epson's Direct Power On and Auto Power On features for quick and easy setup
  • Support for Crestron Connected network monitoring systems
  • Network message broadcast system to project timely messages to all networked projectors

Notes:

Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

Visit epson.com/iprojection (U.S.), epson.ca/iprojection (Canada), or latin.epson.com/iprojection (Caribbean) for more information.

Specifications

General Specifications

Type of display Poly-silicon TFT active matrix
Resolution

1366 x 768 native, 1080 vertical resolution with pixel shifting

Case color White
Lens F = 1.5; Focal length = 3.9 mm
Throw ratio 0.27:1
Color reproduction Full color, up to 1.07 billion colors
Brightness1 Normal Light Source Mode:
  - White light output 5000 lumens
  - Color light output 5000 lumens
Quiet or Extended Light Source Mode:
  - White light output 3500 lumens
Custom mode:
  - White light output 3500 to 5000 lumens
Contrast ratio Over 2,500,000:1 with Dynamic Color Mode, Normal Light Source Mode, and Wide Zoom on
Image size (in native aspect ratio) 65 inches (1.65 m) to 130 inches (3.30 m)
Projection distance (in native aspect ratio) 15.4 inches (0.39 m) to 31.6 inches (0.80 m)
Projection methods Front, rear, wall-mounted, table-mounted, ceiling-mounted
Optical aspect ratio (width-to-height) 16:9
Focus adjustment Manual
Zoom adjustment Digital
Zoom ratio (Tele-to-Wide) 1.0 to 1.35
Internal sound system 8 W × 8 W stereo
Noise level 36 dB (Normal or Extended Light Source Mode)
27 dB (Quiet Light Source Mode)
Keystone correction angle ± 3°
USB Type B port compatibility One USB 2.0 compliant port for USB display, firmware update, or copying menu settings
USB Type A port compatibility

Two USB 2.0 compliant ports for USB memory device, Epson document camera, wireless LAN module connection, firmware update, or copying menu settings

One port for providing power to a streaming media device (5 V, 2 A)

Light Source Specifications

Type Laser Diode
Light source output power Up to 104.5 W
Wavelength 449 to 461 nm
Light source life(approximate) Normal or Quiet Light Source Mode: Up to about 20,000 hours
Extended Light Source Mode: Up to about 30,000 hours

Remote Control Specifications

Reception range 19.7 feet (6 m)
Batteries Two alkaline or manganese AA

Dimensions Specifications

Height (excluding feet) 8.25 inches (209.5 mm)
Width 18 inches (458 mm)
Depth (excluding cable cover) 14.8 inches (375 mm)
Weight (excluding cable cover) 20.7 lb (9.4 kg)

Electrical Specifications

Rated frequency 50/60 Hz
Power supply 100 to 240 VAC ±10%
3.8 to 1.7 A
Power consumption (100 to 120 V) Operating:
Normal or Custom Power Consumption Mode: 381 W
Extended or Quiet Power Consumption Mode: 270 W
Standby:
0.5 W (Communication Off)
2.0 W (Communication On)
Power consumption (220 to 240 V) Operating:
Normal or Custom Power Consumption Mode: 366 W
Extended or Quiet Power Consumption Mode: 262 W
Standby:
0.5 W (Communication Off)
2.0 W (Communication On)

Environmental Specifications

Temperature Operating - Single projector:
  32 to 113 °F (0 to 45 °C)
Operating - Multiple projectors:
  32 to 104 °F (0 to 40 °C)
Storage:
  14 to 140 °F (-10 to 60 °C)
Humidity (relative, noncondensing) Operating: 20 to 80%
Storage: 10 to 90%
Operating altitude Up to 4921 feet (1500 m)
Up to 10000 feet (3048 m) with High Altitude Mode enabled

Notes:

Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

Turn off this product when not in use to prolong the life of the projector. Laser life will vary depending upon mode selected, environmental conditions, and usage. Brightness decreases over time.
