Barco EN59

Ultra Short Throw Lens, 0.28:1
Part #: 0601-0810    Mfr #: R9802235

Barco EN59

Overview

Barco EN59

Ultra short throw lens

The Barco EN59 ultra short throw projector lens takes high-quality, large-screen imaging to the next level. This low-distortion, all-glass lens offers high-quality large-screen projection from a revolutionary short distance.

Offering the world’s shortest throw ratio (0.28:1), you can create a much larger image or a more compact installation. This lens allows you to increase your image size by 263% or shorten your projection distance by 62%!

Allowing you to project on surfaces you thought were impossible, this lens greatly increases installation flexibility. Video walls, digital signage, museums, caves and other installations where people are closely positioned to the projected image will all highly benefit from this groundbreaking lens.

(Article number: R9802235)

Specifications

Working F/# F2.5
Zoom ratio No zoom
Focus Range 0.45 – 1.05 m ( 17.7" to 41.3")
Custom focus range Extended focus range is available, please contact sales for details
Throw Ratio 1080/WUXGA         0.28:1
WQXGA/Panorama  0.30:1
Image size tolerance  ±5%

Same Series Lenses

Model EN59
EN57
EN53 EN52 EN55 EN56 EN51 EN54

Add to Cart

$1,995.00 Add to Cart

Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart
  Barco EN57/EN59 lens Barco EN53 lens Barco EN52 lens Barco EN55 lens Barco EN56 lens Barco EN51 lens Barco EN54 lens
 D:W
WUXGA
0.28:1 0.74:1 0.92:1 0.80  1.08:1 1.06 – 1.62:1 1.60 – 2.21:1 2.5 – 3.9:1
 D:W
WQXGA
0.30:1 0.79:1 0.99:1 0.86  1.16:1 1.14 – 1.74:1 1.71 – 2.37:1 2.67 – 4.16:1
f/stop 2.5 2.6 2.6 2.5 – 2.72 2.5 – 2.72 2.6  3.09 2.6 – 4.18
Notes EN59 replaces EN57
