• Converts any computer signal with a horizontal scan rate between 28K-92KHz and vertical between 56-162Hz to high-quality NTSC video
• Accepts RGsB (sync on Green), RGBS, and RGBHV input signal formats
• Outputs in Composite Video, S-Video, and Y, R-Y, B-Y, Component Video or RGBS formats
• Genlock input with separately adjustable delay and subcarrier phase
• Computer pass-through output
• Overscan/underscan selectable
• Built-in color bar generator to adjust colors accurately
• RS232 control port for external control system support

• Live seamless switching of video, computer, and audio sources
• Mix digital and analog sources
• Upconvert/downconvert multiple video channels between HD and SD
• SD/HD simulcast output
• Pre-programmable video layouts with keyers for picture-in-picture and other effects
• Digital effects with 2D and 3D transformations, including page turns, ripples, and swirls
• Luminance and chroma keyers
• Integrated control of Thomson Grass Valley Turbo™ intelligent digital disk recorder (iDDR), Acappella™ router, and other devices
• Stereo analog and AES/EBU audio
• SDI audio de-embedding and re-embedding
• Four-band parametric equalizer and motor-driven audio faders
• Simple audio-follow-video mode
• Intelligent audio-delay management for live production lip sync

 Spec Sheet

Technical Documents

Installation

Manual

Quick Start Guide

8 universal inputs comprised of 5 BNCs, each of which can accommodate a composite video, s-Video (Y/C), component video (RGB/YUV), RGBS, or RGBHV signal. Inputs 1 and 2 also can be configured to HDMI inputs. Perfect for live mixing where both video and computer sources are present.

• True Seamless Switching with FX - With the incorporation of two scalers, the unit can switch absolutely seamlessly between 2 live sources. Transitions include cut and fade plus numerous other effects each with multiple variations and speeds.
• K-IIT™ Picture-in-Picture Image Insertion Technology - Ultra stable picture-in-picture image insertion capability. Any video source can be inserted into a computer graphics video source and vice versa with positioning and sizing controls available to the user. A unique Split-Screen mode is also available.
• Second set of outputs can be used for preview
• Text Overlay
• HDTV Output Resolutions - 480p, 576p, 720p, 1080i and 1080p in component format on all output connectors.
• Multi-Standard - PAL, SECAM & NTSC (3.58/4.43)
• Multiple Aspect Ratio Selections - 4x3 or 16x9, anamorphic, letter box, and user definable settings
• Built-in Proc-Amp - Color, hue, sharpness, contrast, and brightness are set individually for each input.
• HDCP Compliant - The HDCP (High Definition Content Protection) license agreement allows copy-protected data on the HDMI input to pass only to the HDMI output.
• Companion products VP-727A audio switcher and VP-727T T-Bar Controller are listed below.

Technical Documents

Manual

• Stand alone or VP-727(xl) companion switcher.
• Inputs - 8 stereo audio on RCA connectors.
• Outputs -1 preview output on dual RCA (stereo audio) connectors and 3 program outputs on dual RCA (unbalanced stereo), terminal block (balanced stereo) and a single RCA (S/PDIF) connectors.
• Headphone Output - Program or preview (selectable).
• Level Control - Each input and output.
• Take Button - For executing preview to program switching (with the option to either CUT or FADE (mix) between the audio sources).
• Front Panel Lockout.
• Preview & Program Mute Buttons.
• Audio-Follow-Video - When connected to the VP-727(xl).
• Proc Amp - Base, treble, balance & delay (per input).
• Flexible Control - Front Panel, RS-232 and RS-485 (to connect to VP-727(xl) and VP-727T T-Bar controller).
• Worldwide Power Supply - 100-240V AC.
• Standard 19” Rack Mount Size - 1U. Rack “ears” included.

Technical Documents

Manual

• All VP-727 Functions Replicated - All the front panel controls of the VP-727 and VP-727XL Seamless Switcher are replicated on the VP-727T.
• Convenient Switching Control - Via T-Bar or Take button with selectable transition speed control.
• Menu Button - Control VP-727 via on-screen display on Preview output.
• Wipe Direction Control - Via front panel buttons.
• Control Multiple Units - Up to 4 VP-727 Seamless Switchers can be controlled from one VP-727T.
• Gooseneck Lamp - For low light environments.
• Control - 4 RS-485s to control up to 4 VP-727s and 1 RS-232 for firmware upgrades.
• Power Supply - 12V DC.
• Standard 19” Rack Mount Size - 4RU. Angled faceplate allows for free standing use on a table.

Technical Documents

Manual

• Silicon Optics HQV® Processing: HQV (Hollywood Quality Video) processing represents the state-of-the-art in video processing technology, with the highest quality de-interlacing, noise reduction, and scaling performance for both standard-definition and high-definition signals.
• HDCP compliant
• K-IIT™ Picture-in-Picture image insertion technology
• Video inputs: 4 universal video (composite/s-Video/component), 2 computer graphics video (15-pin HD), 2 HDMI and 1 USB (for JPEG data)
• Scaled video outputs: HDMI and 15-pin HD with support resolutions up to 1920x1080 with selectable refresh rates
• Companion AFV (audio-follow-video) for every analog video input: Supports embedded audio on the 2 HDMI inputs and outputs
• Projector Anywhere™ technology: Horizontal and vertical geometry controls compensate for off-axis projector placement
• Flexible Control Options: Front panel, IR remote (with on-screen menus), and RS-232



Technical Documents

Manual

• Native rate scaler - video is output in the resolution of display device
• Deinterlacer to convert interlaced video to progressive scan
• Switcher with (2) Composite Video, (2) S-Video, (2) Component Interlaced YPrPr or RGB, (1) Progressive YPrPb or RGB, (1) Computer Pass-Through, and (1) DVIinput
• Outputs in both analog RGB and DVI
• Supports 4:3, 16:9, and anamorphic format
• 3:2/2:2 pulldown detection and correction for optimum viewing of movies
• Downloadable firmware (over the Internet using an external computer) to keep product up to date
• RS232 port for external control by third party control systems such as Crestron and AMX
• Screen trigger output for automatic operation of properly equipped motorized screens
• Backlit LCD display plus on-screen display
• IR remote included
