Barco F80-Q12
Overview
12,000 lumens, WQXGA, DLP laser phosphor projector
- Stunning images with superb color performance
- Ultimate installation flexibility, 24/7 operation
- 3D capable
The stunning image quality and laser phosphor light source of Barco's F80 projectors enable you to provide exceptional experiences while saving both time and money. They're designed for fixed installation in a wide range of applications such as museums, board rooms, and auditoriums. Thanks to their 3D capability, they're also perfectly fit for theme park dark rides and interactive experiences.
Superior image quality
The F80-Q12 delivers stunning images with highly saturated colors that allow for accurate color reproduction at all times. What's more it features the powerful Barco Pulse processing that allows for sharper images and less latency thanks to its Single Step Processing (SSP).
Unprecedented business value
With this projector you can increase your uptime while driving costs down. Through its laser-phosphor light source and advanced cooling design, it provides a long operating time without need for lamp changes - resulting in considerable cost-savings on maintenance and consumables.
Ultimate installation flexibility
The F80-Q12 gives you more flexibility in projector location and orientation as it can run in any orientation. Thanks to its wide array of all-glass lenses and wide lens shift ranges, the F80-Q12 accommodates almost any projector configuration.
Features
Key Features
- 12,000 lumens
- WXGA 1280 x 1024 resolution
- laser phosphor projection
- 3D ready
- HDBaseT compliant
- 24/7 operation
Specifications
Specifications
| Projector type | Single-chip DLP laser phosphor projector |
|---|---|
| Technology | 0.67" DMDTM x1 |
| Resolution | 2,716 x 1,600 (WQXGA+ native) |
| Brightness | 11,300 center lumen 10,700 ansi lumen 12,000 ISO lumen |
| Contrast ratio | 1,200:1 sequential, 10,000:1 dynamic** |
| Brightness uniformity | > 90% |
| Aspect ratio | 17:10 native |
| Blend | horizontal and vertical edge blending |
| Lens type | GLD / FLD+ (lens adapter needed) / FLDX (lens adapter needed) |
| Lens range | GLD-range: 0.8 -1.0 ; 1.0 -1.35 ; 1.35 -2.0 ; 2.0 -3.0 |
| Screen size | max 20m |
| Optical lens shift | Vertical up to 125%, depending on lens Horizontal up to 50%, depending on lens Motorized zoom and focus (with lens memory on GLD and FLDX lenses) Motorized lens shift (with position memory on all lenses) |
| Color correction | P7 RealColor™ |
| Light source | Laser phosphor |
| Light source lifetime | > 20000 h in normal mode, > 12000 h in silent mode, > 40000 h in long life mode, > 12000 h in high brightness mode |
| Sealed DLP™ core | Yes -standard |
| Optical dowser | laser dimming |
| Orientation | 360° rotation, no restrictions |
| DMX 512 | standard |
| Image processing | Embedded warp & blend engine direct adjust OSD + Ptoolset |
| Web browser | integrated |
| CLO (constant light output) | Yes |
| 3D | Active stereoscopic 3D / Passive stereo compatible max WQXGA @120Hz |
| Keystone correction |
Yes |
| Inputs |
HDMI2.0 (HDCP2.2, HDR10) / 2x DP 1.2 / 12G-SDI /2x dual link DVI-D / HDBaseT / RJ 45 Ethernet / |
| Input resolutions |
Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz |
| Software tools | Projector Toolset |
| Control | IR, RS232, RJ45, XLR wired |
| 24/7 operation | Yes |
| Network connection | 10/100 Ethernet, RJ45 |
| Power requirements | 100-240V / 50-60Hz |
| Power consumption | 1050 W nominal, 1200 W maximum, < 0.5W standby |
| Noise level (typical at 25°C/77°F) | 35 dB(A) when used in silent mode / 39 dB(A) in normal mode |
| Operational/ambient temperature | 0°-35°C / 32°-95°F |
| Storage temperature | -20 to 60 °C |
| Operational humidity | 0-80% (non-condensating) |
| Storage humidity | 20 -90% RH (non-condensed) |
| Dissipation BTU | max 4100 BTU/h |
| Dimensions (WxLxH) | 480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in |
| Weight | 26.8 kg / 59.1 lbs (without lens) |
| Shipping Dimensions | 583 x 784 x 444 mm / 23.0 x 30.9 x 17.5 inch |
| Shipping Weight | 38.5 kg / 81.6 lbs |
| Standard accessories | Power cord, wireless/XLR wired rugged remote control |
| Certifications | Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS |
| Warranty | 3 years* |
| Notes | * except on light source: 20.000 hrs in normal mode or 3 years ** SW upgradable. Please contact an authorized Barco representative for details. |
Accessories
Optional Lenses
GLD Series
These are the lenses the F80 series of projectors was primarily designed for. Always use a GLD lens when possible.
| P/N | R9801724 | R9801722 | R9801719 Std Lens |
R9801720 | R9801721 |
|
Add to Cart |
Add to Cart |
Add to Cart |
Add to Cart |
Add to Cart |
|
 |
 |
 |
 |
|
|
| D:W WQXGA F80 Legacy |
0.85 – 1.06:1 | 1.06 – 1.43:1 | 1.43 – 2.12:1 | 1.43 – 2.12:1 | 2.12 – 3.18:1 |
| D:W WQXGA+ F80 MKII |
0.8 – 1.0:1 | 1.0 – 1.35:1 | 1.35 – 2.0:1 | 1.35 – 2.0:1 | 2.0 – 3.0:1 |
| f/stop | 2.1 – 2.26 | 2.1 – 2.3 | 2.1 – 2.33 | 2.1 – 2.33 | 2.1 – 2.31 |
| Notes | Motorized | Motorized | Non-Motorized | Motorized | Motorized |
FLD/FLD+/FLDX Series
Recommended when a throw ratio is needed outside the range of GLD series lenses.
| P/N | R9801832 | R9802241 | R9801216 | R9801211 | R9801249 | R9802237 |
| Model | FLDX/UST 90° | FLDX/EN61 | FLD+/EN41 | FLD+/EN44 | FLD/EN16 | FLDX/EN69 |
|
Add to Cart |
Add to Cart |
Add to Cart |
Add to Cart |
Add to Cart |
Add to Cart |
|
 |
 |
|
 |
 |
 |
|
| D:W WQXGA F80 Legacy |
0.57:1 | 2.38 – 3.51:1 | 2.38 – 3.51:1 | 3.51 – 6.45:1 | 5.70 – 9.75:1 | 9.75 – 13.50:1 |
| D:W WQXGA+ F80 MKII |
0.54:1 | 2.25 – 3.30:1 |
2.25 – 3.30:1 |
3.30 – 6.08:1 |
5.37 – 9.19:1 |
9.19 – 12.73:1 |
| f/stop | 2.40 | 2.1 – 2.5 | 2.1 – 2.5 | 2.1 – 2.93 | 2.1 – 2.66 | 2.10 – 2.89 |
| Adapter required | R98014421 | R98014421 | R9801442 | R9801442 | R9801442 | R98014421 |
| Notes | Motorized | Motorized | Motorized | Motorized | Motorized |
